EDM Solution 862 - System Status - AC Fail Report

System Reporting Information 183
System Status – AC Fail Report
LOCATION 348 - 349
2
Location Description
348
System Status – AC Fail Reporting Code (Tens Digit)
349
System Status – AC Fail Reporting Code (Units Digit)
Table 93: System Status – AC Fail Report Locations
An "AC Loss" report (Contact ID Event Code 301) will be transmitted to the base station
receiver when the AC mains supply has been disconnected for two minutes. If you require an
"AC Loss" report to be transmitted to the base station receiver when the AC mains supply has
been disconnected for 1 hour, enable Option 1 in "LOCATION 426" on page 217. If you wish
to ignore AC fail, enable Option 2 in "LOCATION 426" on page 217.
If an "AC Loss" report is not required, program "LOCATION 348 - 349" with a zero.
System Status – AC Fail Restore Report
LOCATION 350 - 351
Location Description
350
System Status – AC Fail Restore Reporting Code (Tens Digit)
351
System Status – AC Fail Restore Reporting Code (Units Digit)
Table 94: System Status – AC Fail Restore Report Locations
A restore signal will be transmitted when the AC mains supply has been restored continuously
for more than two minutes.
If an "AC Loss” restore report is not required, program "LOCATION 350 - 351" with a
zero.
