EDM Solution 862 - Turning Outputs On;Off

102
Solution 862
Installation Manual
5
How To Disable STAY Mode 2 Zones
If at any time you wish to disable all zones selected to be automatically isolated for STAY
followed by
4
and the button, followed by
th
Mode 2, you may enter your
e
button.
+
4
+
+
Turning Outputs On/Off
If an output has been programmed for remote operation, you can turn the remote output on or
off using this Master Code function or remotely using the Alarm Link Software.
For this Master Code Function to operate, one or more of the following output event types need
to be programmed in any of the programmable outputs.
Output Number 1 = Output Event Type – 2,8 on page 197.
Output Number 2 = Output Event Type – 2,9 on page 197.
Output Number 3 = Output Event Type – 2,10 on page 197.
How To Turn An Output On From The Remote Codepad
1.
Enter your
followed by
5
and the button.
Three beeps will be heard and the
STAY
and
AWAY
indicators will begin to flash.
2.
Enter the required
(1-3) followed by the button.
Three beeps will be heard and the output will now turn on. Repeat step 2 if more than
one output is required to be turned on.
3.
Press the
button again to exit this function.
Two beeps will be heard and the
STAY
and
AWAY
indicators will extinguish.
+
5
+
+ + +
Example
If Output 2 has been programmed as
281000
in “LOCATION 374 – 379”, the
Master Code holder may turn on this output following the steps outlined below;
2580
+
5
+
+
1
+ +
ISSUE130 Electronics Design and Manufacturing Pty Limited
