88
Solution 862
Installation Manual
8
Example
Event Memory Recall Mode
This function allows you to playback the last forty events that have occurred to the system.
The event memory recall mode reports all alarms and arming/disarming of the system in the
AWAY Mode, STAY Mode 1 and STAY Mode 2. This function helps with trouble shooting
system faults. The events are displayed via the codepad indicators.
How To Enter The Event Memory Recall Mode
1.
Enter your followed by
8
and the button.
Three beeps will be heard. The events will be played back via the codepad indicators in
reverse chronological order.
+
8
+
If the events were as follows:
Event No Event Description
1
System Armed In AWAY Mode
2
Alarm In Zone 3
3
Alarm In Zone 4
4
System Disarmed
Table 31: Event Memory Recall - Example Events
The event memory playback will report as follows:
Event No Codepad Indicator Event Description
4
All Indicators Off Except MAINS System Disarmed
3
Zone 4 + AWAY Indicator Illuminates Alarm In Zone 4
2
Zone 3 + AWAY Indicator Illuminates Alarm In Zone 3
1
AWAY Indicator Illuminates System Armed In AWAY Mode
Table 32: Event Memory Recall - Example Event Playback
A beep and an illuminated codepad indicator indicate each event. Resetting a 24-hour alarm in
the disarmed state is indicated by one beep only. After the last event, three beeps will be heard
to indicate the end of playback. The replay of event memory can be terminated at any time by
pressing the
button.
If the system is armed in STAY Mode 1 or STAY Mode 2, the STAY indicator will display
the event memory playback. There is no differentiation between arming the system in
STAY Mode 1 and STAY Mode 2.
If the control panel has been powered down, the memory of all events will be lost.
Reserved
9
ISSUE130 Electronics Design and Manufacturing Pty Limited
