STAY Indicator
The
STAY
indicator is used to display that the system is armed in STAY Mode 1 or STAY
Mode 2. The
STAY
indicator will also flash in unison with the
AWAY
indicator when
Installer’s Programming Mode or Master Code Functions are used.
The
indicator will also illuminate when the system is armed in STAY Mode 1 or STAY
Mode 2.
Refer to page 54 for the different methods of arming the system in STAY Mode 1. Refer to
Zone Options 1 on page 167 for information on setting zones to be automatically isolated in
STAY Mode 1. For the method of arming the system in STAY Mode 2, refer to page 57.
Refer to Setting STAY Mode 2 Zones on page 85 when using the Installer Code or Setting
STAY Mode 2 Zones on page 101 when using the Master Cod to program zones to be
automatically isolated in STAY Mode 2.
Indicator Definition
On
System Is Armed In STAY Mode 1 Or STAY Mode 2
Off
System Is Not Armed In STAY Mode
Flashing
Zone Isolating Mode Or Setting STAY Mode 2 Zones
Table 16: STAY Indicator
System Disarmed
This indicator will illuminate with the indicator when the system has been disarmed.
MAINS Indicator
The
MAINS
indicator is used to display that the systems AC mains supply is normal or has
failed.
When programming numbers (i.e. Installer’s Programming Mode or Master Code Functions),
the
MAINS
indicator will illuminate when you program numbers between 10 and 15. The
MAINS
indicator represents digit 10 plus the value of the illuminated zone indicator (e.g.: If
you program a twelve, the
MAINS
indicator and zone 2 will illuminate).
Indicator Definition
On
AC Mains Power Normal
Flashing
AC Mains Failure
Table 17: MAINS Indicator
Zone Isolating Mode
Flashing
This indicator will flash once every 3 seconds when you attempt to isolate zones or program
zones to be automatically isolated for STAY Mode 2. The person will flash once every 3
seconds.
Refer to Isolating Zones on page 60 for information on how to manually isolate zones. Refer to
Setting STAY Mode 2 Zones on page 85 when using the Installer Code or Setting STAY Mode
2 Zones on page 101 when using the Master Cod to program zones to be automatically isolated
in STAY Mode 2.
