System Operations 65
Fuse Fail
7
This fault will occur when either the 1 Amp – 12 V accessories fuse or the 1 Amp codepad fuse
has failed. After 10 seconds has expired since the fuse had failed, the control panel will
automatically send a System Trouble code (Contact ID Event Code 300) to the base station
receiver. After the fuse has been replaced for a period of 10 seconds, a restore report will be
sent to the base station receiver.
If both the 1 Amp – 12 V accessories fuse and the 1 Amp codepad fuse have failed, only
one system trouble report will be sent to the base station receiver. Only after both fuses
have been replaced will any system trouble restore report will be sent to the base station
receiver.
Communication Failure
8
A communication failure fault will register if the primary telephone number and secondary
telephone number for either Receiver 1 or Receiver 2 is unsuccessful in calling the receiving
party.
When a communications fault occurs, to determine which receiver failed to report, hold down
the
8
button for two seconds until two beeps are heard. If Receiver 1 failed to report, zone 1
will illuminate. If Receiver 2 failed to report, zone 2 will illuminate.
If the primary telephone number and secondary telephone number for Receiver 1 or Receiver 2
is set up for back to base reporting, Receiver 1 or Receiver 2 has a maximum of twelve call
attempts per event to call the base station receiver (If both Receiver 1 and Receiver 2 have the
primary telephone number and secondary telephone number programmed, the maximum
number of calls will total 24 providing that the event is allocated to report on both receivers).
The control panel will attempt to call the base station receiver up to six times using both the
primary telephone number and the secondary telephone number (Only three times if the
primary telephone number is programmed). If at this stage the control panel has failed to
communicate to the base station receiver, a communications fault will occur and the control
panel will wait 10 minutes before attempting to report to the base station receiver for a further
6 attempts. The communication fault will reset on the next successful call attempt.
If Receiver 1 or Receiver 2 is set up for domestic reporting, the control panel will not
display a fault if failed to report after the maximum of six call attempts.
If Option 1 in “LOCATION 177” on page 145 is enabled and there are no telephone
numbers programmed, no fault condition will occur.
Electronics Design and Manufacturing Pty Limited ISSUE130
