Codepad Indicators 45
STAY Indicator
The
STAY
indicator is used to display that the system is armed in STAY Mode 1 or STAY
Mode 2. The
STAY
indicator will also flash in unison with the
AWAY
indicator when
Installer’s Programming Mode or Master Code Functions are used.
Refer to page 54 for the different methods of arming the system in STAY Mode 1. Refer to
Zone Options 1 on page 167 for information on setting zones to be automatically isolated in
STAY Mode 1. For the method of arming the system in STAY Mode 2, refer to page 57.
Refer to Setting STAY Mode 2 Zones on page 85 when using the Installer Code or Setting
STAY Mode 2 Zones on page 101 when using the Master Code.
Indicator Definition
On
System Is Armed In STAY Mode 1 Or STAY Mode 2
Off
System Is Not Armed In STAY Mode
Flashing
Zone Isolating Mode Or Setting STAY Mode 2 Zones
Table 10: STAY Indicator
MAINS Indicator
The
MAINS
indicator is used to display that the systems AC mains supply is normal or has
failed.
When programming numbers (i.e. Installer’s Programming Mode or Master Code Functions),
the
MAINS
indicator will illuminate when you program numbers between 10 and 15. The
MAINS
indicator represents digit 10 plus the value of the illuminated zone indicator (e.g.: If
you program a twelve, the
MAINS
indicator and zone 2 will illuminate).
Indicator Definition
On
AC Mains Power Normal
Flashing
AC Mains Failure
Table 11: MAINS Indicator
FAULT Indicator
The
FAULT
indicator is used to display that the system has detected a system fault. Refer to
Fault Analysis Mode on page 63 for more information on system faults.
Every time a new system fault has been detected (e.g.:
FAULT
indicator flashing), the codepad
will begin to beep once every minute.
Pressing the button once will cancel the once a minute beep and acknowledge the fault
(e.g.:
FAULT
indicator on).
Indicator Definition
On
There Is A System Fault That Needs To Be Rectified
Off
The System Is Normal, There Are No Faults
Flashing
There Is A System Fault Waiting To Be Acknowledged
Table 12: FAULT Indicator
Electronics Design and Manufacturing Pty Limited ISSUE130
