Solution 862
Installation Manual
Command 958 - Enable/Disable Zone Status Mode
This function enables and disables the zone status display mode when using the hand held
programmer. The hand held programmer will display the zones on the seven-segment display
from left to right. If there is a dash illuminated on the display of the hand held programmer,
the corresponding zone is unsealed and if the display is blank, the zone is sealed.
The third (or centre) display shows either the number 4 or the number 8. The number 4
constantly illuminated indicates that zones 1 - 4 are being displayed. The number 8 constantly
illuminated indicates that zones 5 - 8 are being displayed.
Pressing the
#
button will toggle the display between the zones. This feature will prove to be
very useful during installation as the hand held programmer allows you to view the status of
the zones directly at the control panel, saving you time and money.
How To Enable Zone Status Mode
1.
Enter Installers Programming Mode (i.e.
1234
followed by the
#
button).
Two beeps will be heard and the hand held programmer will display the data currently
programmed in “LOCATION 000”.
2.
Enter command
958
followed by the
#
button.
Two beeps will be heard and the number 4 will illuminate to indicate zones 1 – 4 are
being displayed.
How To Disable Zone Status Mode
1.
Enter command
958
followed by the
#
button.
Two beeps will be heard and you will return to the Installer’s Programming Mode.
Example
A " - " in the display indicates the zone is unsealed.
A blank display indicates the zone is sealed.
À-4--
indicates that zone 1 is sealed and zones 2, 3 and 4 are unsealed.
À
À8À-
indicates that zones 5 and 8 are unsealed and zones 6 and 7 are sealed.
À
