192
Solution 862
Installation Manual
Output Event Types
There are approximately seventy five different output event types to choose from. Two
numbers designate each output event type. These two numbers need to be programmed into
the appropriate locations of the output being used to indicate when the output should operate.
All reset times are in reference to polarity 1 and 8. Reset times will vary depending on
the polarity used.
00
EDMSAT - Satellite Siren (Output 1 Only)
This output controls all functions of an EDMSAT satellite siren (SS914). The
option of speaker indication beeps will not operate via the EDMSAT for remote
operations. No polarity is required to be programmed for this output event type.
01
System Armed
This output will operate when the system is armed in AWAY Mode, STAY Mode 1
or STAY Mode 2. The output will reset when the system has been disarmed.
02
System Disarmed
This output will operate when the system is in the disarmed state. The output will
reset as soon as the system becomes armed.
03
Armed In STAY Mode
This output will operate when the system has been armed in STAY Mode 1 or
STAY Mode 2. The output will reset when the system is disarmed.
04
Armed In AWAY Mode
This output will operate when the system has been armed in AWAY Mode. The
output will reset when the system is disarmed.
05
Auto Arm Pre-Arming Alert Time
This output will operate during the time period before the control panel will
automatically arm in AWAY Mode or STAY Mode 1. Once the control panel has
automatically armed in AWAY Mode or STAY Mode 1, the output will reset. To
program the pre-arming alert time, refer to “LOCATION 413” on page 208.
06
Exit Warning With All Zones Sealed Or Entry Warning
This output will operate during exit time when the control panel has been armed in
AWAY Mode, STAY Mode 1 or STAY Mode 2 if all zones are sealed. This output
event type will reset once exit time has expired.
The next time this output event type will operate will be during entry time and will
reset once entry time has expired or the system has been disarmed. This output
event type will also operate if a zone has triggered when the system has been armed
in STAY Mode 1 or STAY Mode 2 only if the Entry Guard Timer For STAY Mode
has been programmed in "LOCATION 404 - 405" on page 205.
07
Exit Warning
This output operates during exit time when the system has been armed in AWAY
Mode, STAY Mode 1 or STAY Mode 2. The output will reset once exit time has
expired.
ISSUE130 Electronics Design and Manufacturing Pty Limited
