08
Exit Warning Finished
This output operates when the exit time has expired when the system has been
armed in AWAY Mode, STAY Mode 1 or STAY Mode 2. The output will reset
when the system has been disarmed.
09
Kiss-Off After Exit Time
This output will operate after the first successful transmission to the base station
receiver when exit time has expired. The output will reset when the system has been
disarmed.
0
Entry Warning
This output will operate when either Entry Timer 1, Entry Timer 2 or Entry Guard
Timer For STAY Mode are operating. The output will reset when the entry time
expires.
0
Entry Warning + Day Alarm Resetting
This output combines both Entry Warning and Day Alarm Resetting so that either of
these two events will activate the output.
If the output has been triggered by either Entry Timer 1, Entry Timer 2, or Entry
Guard Timer For STAY Mode, the output will reset once the entry timer has expired
or the system has been disarmed.
If a zone programmed for day alarm has triggered during the disarmed state, the
output will reset when the zone has resealed. alarm may be turned on and off
by holding down the
4
button. Refer to Day Alarm Zones on page 156 for
programming zones to operate for day alarm.
0
Exit Warning + Entry Warning + Day Alarm Resetting
This output combines exit warning, entry warning and day alarm so that any of these
three events will activate the output.
This output will activate once the system has been armed in AWAY Mode, STAY
Mode 1 or STAY Mode 2 irrespective of any zones being sealed or unsealed until
exit time expires.
The next time the output will activate will be during entry time and will reset once
entry time has expired or the system has been disarmed. his output will also
operate when the Entry Guard Timer For STAY Mode is timing.
If a zone programmed for day alarm has triggered during the disarmed state, the
output will reset when the zone has resealed. alarm may be turned on and off
by holding down the
4
button. Refer to Day Alarm Zones on page 156 for
programming zones to operate for day alarm.
0
Day Alarm Resetting
This output will operate when a zone programmed for day alarm has been triggered.
The output will reset when the day alarm zone has resealed. Day alarm may be
turned on and off by holding down the
4
button. Refer to Day Alarm Zones on
page 156 for programming zones to operate for day alarm.
0
Day Alarm Latching
This output will operate when a zone programmed for day alarm has been triggered.
The output will reset when the
button has been pressed. ay alarm may be
turned on and off by holding down the
4
button. Refer to Day Alarm Zones on
page 156 for programming zones to operate for day alarm.
Programmable Outputs 193
Electronics Design and Manufacturing Pty Limited ISSUE130
