Remote Radio Transmitter Operations 73
There are two remote outputs than can be operated from the DOOR and AUX buttons on the 4-
channel hand held transmitter. These outputs can only be programmed by the installer. The
output event types that can be used are listed in the table below. Refer to the section on
Programmable Outputs on page 189 for more information.
Output Event Type Description Page
2,11
Radio Control Output 1 197
2,12
Radio Control Output 2 197
2,13
Radio Control Output 1 – Not Armed In AWAY Mode 197
2,14
Radio Control Output 2 – Not Armed In AWAY Mode 197
Table 24: Remote Output Event Types
Turning Output 1 ON
1.
Press the DOOR button on the hand held transmitter for two seconds.
Output 1 will now turn on.
Turning Output 1 OFF
1.
Press the DOOR button on the hand held transmitter for two seconds.
Output 1 will now turn off.
Turning Output 2 ON
1.
Press the AUX button on the hand held transmitter for two seconds.
Output 2 will now turn on.
Turning Output 2 OFF
1.
Press the AUX button on the hand held transmitter for two seconds.
Output 2 will now turn off.
All reset times of the remote DOOR and AUX buttons are in reference to polarity 1 and 8.
Reset times will vary depending on the polarity used.
Electronics Design and Manufacturing Pty Limited ISSUE130
