224
Solution 862
Installation Manual
Optional Equipment
EDM manufactures numerous accessories that can be used in conjunction with the
Solution
862
control panel. These optional pieces of equipment will enhance certain features thus
making the system extremely flexible.
2 Channel/4 Channel Hand Held Transmitters 304 Mhz (RE012/RE013)
These hand held radio transmitters can be used in conjunction with the 304 Mhz RF Receiver
(WE800) to remotely operate the system. Both hand held transmitters have the ability to
remotely arm and disarm the system in AWAY Mode or STAY Mode 1 and activate remote
panic alarms. The 4 channel hand held transmitter has the added ability to operate outputs such
as garage doors, swimming pool pumps or outside lights etc.
304 Mhz RF Receiver (WE800)
This interface was designed to allow the use of up to eight radio user codes (9 – 16). This is
useful if you require the system to be radio controlled and you would like to give your
customer total control via a radio hand held remote transmitter.
Figure 11: Solution Wireless ON/OFF Interface (WE800)
2 Channel Radio Interface (RE005)
The EDM 2 channel radio interface has been designed to allow customers to remotely operate
Solution control panels and control two on-board relays. The interface may also be used as a
stand alone receiver, independent of a Solution control panel and used solely for remote control
of external devices connected to the two on-board relays.
The interface’s operating frequency is 304 Mhz with the ability to store up to 120 radio remote
codes. When connecting the interface to a Solution control panel, there is only a three wire
connection in parallel to the codepad and Option 8 in “LOCATION 427” on page 218 needs to
be programmed.
ISSUE130 Electronics Design and Manufacturing Pty Limited
