226
Solution 862
Installation Manual
Hand Held Dialler Tester (DD901)
The hand held dialler tester simulates a base station for testing of the control panel's dialling
functions. It communicates in most formats.
Cellular Diallers
The cellular dialler when connected to the control panel will transmit alarm information via the
cellular phone network to the base station receiver when a land telephone line is not present or
has been tampered with.
PS100 Power Supply Module (PS100
)
The PS100 Power Supply Module has been designed for applications requiring 13.8 volts DC
at currents of up to 1 Amp and must be used in conjunction with the TF008 - 18 volt AC plug
pack.
The unit comes complete with our standard, fully short circuit proof, power out and battery
charging terminals as well as a DC LED indicator and AC mains fail output. For situations
requiring an uninterrupted power source, a rechargeable sealed lead-acid battery can be
connected. In the event of an AC mains failure, the power supply will switch to battery power
without interrupting the load being supplied.
TF008 Plug Pack (TF008)
The TF008 plug packs have been designed to be used with the EDM control panels and the
PS100 Power Supply Module. The plug pack includes built in thermal fuses which under
overload or fault conditions will blow and eliminate any possible fire threat due to excessive
heat build up inside the casing.
The TF008 plug pack incorporates a three wire flying lead that enables a mains earth
connection to be made between the equipment and the plug pack. This connection may be
required for lightning protection on equipment that is connected to phone lines or for safety
reasons such as earthing of metal enclosures.
Solution Codepad Mimic Board (CC820)
The Solution Codepad Mimic Board (CC820) has been designed to allow you to have a
separate output indicator for each indicator found on the remote codepad. This will be useful
to remotely display system status information.
ISSUE130 Electronics Design and Manufacturing Pty Limited
