248
Solution 862
Installation Manual
Location 265
Page 156
Day A
8 = Zone 4
Location 266
Page 158
EOL Resistor Value
0 = No End Of Line Resistor
1 = 1K
9 = 10K
10 = 12K
2 = 1K5 11 = 22K
3 = 2K2 12 = Reserved
4 = 3K3 13 = Reserved
5 = 3K9 14 = Reserved
6 = 4K7 15 = Split EOL (3K3/6K8) – Six Burglary
7 = 5K6
8 = 6K8
Zones and Two 24 Hour Zones
15
larm Zones
1 = Zone 1
2 = Zone 2
4 = Zone 3
0
Location 267 – 322
Page 161
Zones
Zone 1
Location 267 - 273
Zone 2
Location 274 - 280
2 0 0 1 14 1 1 1 0 0 1 14 1 1
Zone 3
Location 281 - 287
Zone 4
Location 288 - 294
Zone 5
Location 295 – 301
1 0 0 1 14 1 1 1 0 0 1 14 1 1 0 0 0 1 14 1 1
Zone 6
Location 302 - 308
Zone 7
Location 309 - 315
Zone 8
Location 316 - 322
0 0 0 1 14 1 1 13 0 0 1 12 1 1 9 0 0 1 12 1 1
Zone Zone Pulse Zone Pulse Zone Zone Report Dialler
Type Count Count Time Option 1 Option 2 Code Options
Zone Types
There are fifteen different zone types to choose from. Each zone contains eight locations. Zones 1 to 6 are fully
programmable whereas zones 7 and 8 may only be programmed to any 24 hour zone type.
Zone Type Description Zone Type Description
0
Instant
8
24 Hour Hold-Up
1
Handover
9
24 Hour Tamper
2
Delay-1
10
Reserved
3
Delay-2
11
Keyswitch
4
Reserved
12
24 Hour Burglary
5
Reserved
13
24 Hour Fire
6
24 Hour Medical
14
Chime Only
7
24 Hour Panic
15
Zone Not Used
Table 134: Available Zone Types
