Location 344 – 345
Page 182
System Status – Fuse Fail Report
Location 346 – 347
Page 182
System Status – Fuse Fail Restore Report
Location 348 – 349
Page 183
System Status
–
AC Fail Report
Location 350 – 351
Page 183
System Status - AC Fail Restore Report
Location 352 – 353
Page 184
System Status - Low Battery Report
Location 354 – 355
Page 185
System Status - Low Battery Restore Report
Location 356 – 358
Page 185
System Status – Access Denied
Location 359
Page 186
System Status Reporting Options
Location 360 – 366
Page 186
Test Reporting Time
Location 367
Page 187
Test Reporting Dialler Options
Location 368 – 397
Page 190
Output
Configurations
10 3
10 8
10 2
10 7
10 1
10 6
Location 356 Code Retries
Location 357 Reporting Code – Tens Digit
Location 358 Reporting Code – Units Digit
6 7 12
1
0 = No Report Required
1 = Receiver 1
2 = Receiver 2
4 = Receiver 1 + 2
8 = Receiver 2 Only When Receiver 1 Fails
Location 360 Actual Hour Of The Day (Tens Digit)
Location 361 Actual Hour Of The Day (Units Digit)
Location 362 Actual Minute Of The Day (Tens Digit)
Location 363 Actual Minute Of The Day (Units Digit)
Location 364 Test Report Code (Tens Digit)
Location 365 Test Report Code (Units Digit)
Location 366 Repeat Interval In Days
0 0 0 0 7 1 0
1
0 = No Report Required
1 = Receiver 1
2 = Receiver 2
4 = Receiver 1 + 2
8 = Receiver 2 Only When Receiver 1 Fails
Location 368 - 373
Location 374 - 379
Location 380 - 385
Output 1
1 14 0 0 0 0
Output 2
2 7 10 2 1 5
Strobe
2 0 6 4 0 8
Default For
Horn Speaker
Default For
Fire Alarm Verification
Default For Strobe
(Reset In 8 Hrs)
Location 386 – 391
Location 392 – 397
Relay
1 15 1 0 0 0
Codepad
0 13 2 1 0 1
Default For
Sirens Running
Default For Entry/Exit
Warning + Day Alarm
Event Type Polarity Time Base Time Multiplier
Solution 862
Programming Sheets 251
Electronics Design and Manufacturing Pty Limited ISSUE130
