Parameter 07.037 Temperature Nearest To Trip Level
Short description
Displays the location or the model that corresponds to the value shown in Percentage Of Drive Thermal
Trip Level
Mode Open‑loop
Minimum 0 Maximum 29999
Default Units
Type 32 Bit Volatile Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
TemperatureNearestToTripLevel (07.037) shows the location or the model that corresponds to the value shown in PercentageOfDriveThermalTripLevel (07.036) in the form xxyzz as shown
in the table below.
Source xx y zz
Control system 00 1 00: Inverter thermal model ( InverterTemperature (07.034) )
Control system 00 2 00: D.c. link thermal model ( PercentageOfd.c.LinkThermalTripLevel (07.035) )
Power system 01 0
zz: Thermistor location defined by zz in the power system ( StackTemperature (07.004) or
AuxiliaryTemperature (07.005) )
Power system (Large frame
only)
01 1 zz: Thermistor location defined by zz in the rectifier
Parameter 07.046 Thermistor Type
Short description Defines the thermistor type when used
Mode Open‑loop
Minimum 0 Maximum 4
Default 0 Units
Type 8 Bit User Save Update Rate Background write
Display Format Standard Decimal Places 0
Coding RW, TE
Value Text
0 D44081
1 84
2 PT1000
3 PT2000
4 Other
ThermistorType (07.046) defines the operation of the temperature feedback interface for DI/O 05 when Digitalinput5mode (08.035) is 1, 2 or 3.
If ThermistorType (07.046) = 0, the thermistor DIN44081 is designed to react like a temperature switch and therefore ThermistorTemperature (07.050) always reads 0.0°C.
If ThermistorType (07.046) = 1 to 3 is selected, the digital input operation of the terminal is disabled.
If ThermistorType (07.046) = 4, any thermistor can be used but ThermistorTemperature (07.050) always reads 0.0°C.
Parameter 07.047 Thermistor Feedback
Short description Displays the measured resistance of the thermistor when used
Mode Open‑loop
Minimum 0 Maximum 4000
Default Units Ω
Type 16 Bit Volatile Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, FI, ND, NC, PT
ThermistorFeedback (07.047) shows the measured resistance. If Digitalinput5mode (08.035) is 2 then {Th} trip is initiated if the feedback value is higher than ThermistorTripThreshold
(07.048). The trip cannot be reset unless the feedback is below ThermistorResetThreshold (07.049). The default values for ThermistorTripThreshold (07.048) and ThermistorResetThreshold
(07.049) are the levels specified in the DIN 44082 standard.
Parameter 07.048 Thermistor Trip Threshold
Short description Defines the thermistor trip threshold when used
Mode Open‑loop
Minimum 0 Maximum 4000
Default 3300 Units Ω
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW
See ThermistorFeedback (07.047).
Parameter 07.049 Thermistor Reset Threshold
Short description Defines the thermistor reset threshold when used
Mode Open‑loop
Minimum 0 Maximum 4000
Default 1800 Units Ω
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW
See ThermistorFeedback (07.047).
Parameter 07.050 Thermistor Temperature
Short description
Displays the temperature of the device based on the resistance to temperature characteristic for the
specified device
Mode Open‑loop
Minimum -50 Maximum 300
Default Units °C
Type 16 Bit Volatile Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, FI, ND, NC, PT
