Timer 1 Repeat Function (09.039) Repeat period Second Minute Hour Day Month Year Day of week
0 None
1 Hour • •
2 Day • • •
3 Week • • • •
4 Month • • • •
5 Year • • • • •
6 One off • • • • • •
7 Minute •
AsTimer1Invert inverts the timer output it can be used to give an active state of 0 instead of 1. Alternatively it can be used to give an active state of 1,
but for a time period that spans the ends of the repeat period as shown in the example above. It should be noted that if this method is used to allow the
active period to span the ends of the repeat period then if the timer is disabled the output of the timer block before the invert becomes 0, and so the final
output of the timer after the invert is 1.
If Date/TimeSelector (06.019) is changed and the drive is reset then the source for the timers will change, therefore Timer1RepeatFunction (09.039)
and Timer2RepeatFunction (09.049) are reset to 0 to disable the timers and the date and time entries in the trip log are cleared.
Parameter 09.001 Logic Function 1 Output
Short description Shows the output state of logic function 1
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 4ms write
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
LogicFunction1Output (09.001) shows the output of logic function 1.
Parameter 09.002 Logic Function 2 Output
Short description Shows the output state of logic function 2
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 4ms write
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
LogicFunction2Output (09.002) shows the output of logic function 2.
Parameter 09.003 Motorised Pot Output
Short description Shows the output level of the motorised pot function
Mode Open‑loop
Minimum -100.00 Maximum 100.00
Default Units %
Type 16 Bit Power Down Save Update Rate 4ms write
Display Format Standard Decimal Places 2
Coding RO, ND, NC, PT
MotorisedPotOutput (09.003) shows the output of the motorised pot function.
Parameter 09.004 Logic Function 1 Source 1
Short description Defines input source 1 of logic function 1
Mode Open‑loop
Minimum 0.000 Maximum 30.999
Default 0.000 Units
Type 16 Bit User Save Update Rate Drive reset read
Display Format Standard Decimal Places 3
Coding RW, PT, BU
Unidrive M200 Parameter Reference Guide
Issue: 01.05.00.10
129
