Parameter 10.069 Additional Status Bits
Short description Shows the additional status bits for the drive
Mode Open‑loop
Minimum
0
(Display: 000000000000)
Maximum
4095
(Display: 111111111111)
Default Units
Type 16 Bit Volatile Update Rate Background write
Display Format Binary Decimal Places 0
Coding RO, ND, NC, PT
The bits in AdditionalStatusBits (10.069) mirror the status bits parameters as shown below. Where the parameters do not exist in any mode the bit remains at zero.
Bit Status parameter
0 Reserved
1 MotorOverloadAlarm (10.017)
2 DriveOver-temperatureAlarm (10.018)
3 DriveWarning (10.019)
4 Reserved
5 Reserved
6 RemoteKeypadBatteryLow (10.064)
7 Auto-tuneActive (10.065)
8 Limitswitchactive (10.066)
9 Reserved
10 LowACAlarm (10.107)
11 Currentlimitactive (10.009)
Because of the limited number of segments on drives with an LED display, these drives will indicate the parameter value as a
decimal value rather than a binary value.
Parameter 10.070 Trip 0 Sub-trip Number
Short description Shows the sub-trip number for trip 0
Mode Open‑loop
Minimum 0 Maximum 65535
Default Units
Type 16 Bit Power Down Save Update Rate Write on trip
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT, BU
See Trip0 (10.020).
Parameter 10.071 Trip 1 Sub-trip Number
Short description Shows the sub-trip number for trip 1
Mode Open‑loop
Minimum 0 Maximum 65535
Default Units
Type 16 Bit Power Down Save Update Rate Write on trip
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT, BU
See Trip0 (10.020).
Parameter 10.072 Trip 2 Sub-trip Number
Short description Shows the sub-trip number for trip 2
Mode Open‑loop
Minimum 0 Maximum 65535
Default Units
Type 16 Bit Power Down Save Update Rate Write on trip
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT, BU
See Trip0 (10.020).
Parameter 10.073 Trip 3 Sub-trip Number
Short description Shows the sub-trip number for trip 3
Mode Open‑loop
Minimum 0 Maximum 65535
Default Units
Type 16 Bit Power Down Save Update Rate Write on trip
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT, BU
See Trip0 (10.020).
