Parameter 01.014 Reference Selector
Short description Defines the source for the reference
Mode Open‑loop
Minimum 0 Maximum 6
Default 0 Units
Type 8 Bit User Save Update Rate 4ms read
Display Format Standard Decimal Places 0
Coding RW, TE
Value Text Description
0 A1.A2 Analogue reference 1 or 2 selected by terminal input
1 A1.Pr Analogue reference 1 or Presets selected by terminal input
2 A2.Pr Analogue reference 2 or Presets selected by terminal input
3 Preset Preset reference selected by terminal
4 Pad Keypad reference selected
5 Res Reserved
6 Pad.Ref Keypad reference selected but no control mode
See ControlWordEnable (06.043) which will take priority over ReferenceSelector (01.014).
ReferenceSelector (01.014) is automatically set up when a new drive configuration is programmed (see DriveConfiguration (11.034) ).
ReferenceSelector (01.014) defines how ReferenceSelectedIndicator (01.049) is derived. If ReferenceSelector (01.014) is not set to 0
ReferenceSelectedIndicator (01.049) is equal to ReferenceSelector (01.014). If ReferenceSelector (01.014) = 0 then ReferenceSelectedIndicator (01.049) is
controlled by the reference select flags as shown below. The higher numbered flags have priority over the lower numbered flags.
Reference select flag states Reference Selected Indicator (01.049)
All reference select flags equal to 0 1
ReferenceSelectFlag1 (01.041) = 1 2
ReferenceSelectFlag2 (01.042) = 1 3
ReferenceSelectFlag3 (01.043) = 1 4
PresetSelector (01.015) defines how PresetSelectedIndicator (01.050) is derived as shown below.
Preset Selector
(01.015)
Preset Selected Indicator (01.050)
0 Controlled by the preset select flags (01.045 to 01.047)
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9
Controlled by the present reference selector timer (see
PresetSelectorTimer (01.016))
When PresetSelector (01.015) = 0 then PresetSelectedIndicator (01.050) is defined by the preset select flags as shown below.
PresetSelectFlag3
(01.047)
PresetSelectFlag2
(01.046)
PresetSelectFlag1
(01.045)
PresetSelectedIndicator
(01.050)
0 0 0 1
0 0 1 2
0 1 0 3
0 1 1 4
1 0 0 5
1 0 1 6
1 1 0 7
1 1 1 8
ReferenceSelectedIndicator (01.049) and PresetSelectedIndicator (01.050) then define the reference to be used as shown below.
