Menu 3 Single Line Descriptions − Frequency Monitoring and Speed
Feedback
Mode: Open‑loop
Parameter Range Default Type
03.001 Final Demand Reference ±VM_FREQ Hz RO Num ND NC PT FI
03.005 Zero Frequency Threshold 0.00 to 20.00 Hz 2.00 Hz RW Num US
03.006 At Frequency Lower Limit 0.00 to 550.00 Hz 1.00 Hz RW Num US
03.007 At Frequency Upper Limit 0.00 to 550.00 Hz 1.00 Hz RW Num US
03.008 Over Frequency Threshold 0.00 to 550.00 Hz 0.00 Hz RW Num US
03.009 Absolute At Frequency Select Off (0) or On (1) Off (0) RW Bit US
03.022 Hard Frequency Reference ±VM_SPEED_FREQ_REF Hz 0.00 Hz RW Num US
03.023 Hard Frequency Reference Select Off (0) or On (1) Off (0) RW Bit US
03.029 Position 0 to 65535 RO Num ND NC PT FI
03.032 Position Counter Reset Off (0) or On (1) Off (0) RW Bit NC
03.035 Position Scaling Numerator 0.000 to 1.000 1.000 RW Num US
03.036 Position Scaling Denominator 0.000 to 100.000 1.000 RW Num US
03.037 Frequency Output or PWM Output Scaling 0.000 to 4.000 1.000 RW Num US
03.038 Maximum Output Frequency 1 (0), 2 (1), 5 (2), 10 (3) kHz 5 (2) kHz RW Txt US
03.042 Frequency Input High Precision Off (0) or On (1) Off (0) RW Bit US
03.043 Maximum Reference Frequency 0.00 to 100.00 kHz 10.00 kHz RW Num US
03.044 Frequency Reference Scaling 0.000 to 4.000 1.000 RW Num US
03.045 Frequency Reference 0.00 to 100.00 % RO Num ND NC PT FI
03.047 Two Point Minimum Frequency 0.00 to 100.00 % 0.00 % RW Num US
03.048 Drive Reference at Minimum Frequency 0.00 to 100.00 % 0.00 % RW Num US
03.049 Two Point Maximum Frequency 0.00 to 100.00 % 100.00 % RW Num US
03.050 Drive Reference at Maximum Frequency 0.00 to 100.00 % 100.00 % RW Num US
03.072 Motor speed percent ±150.0 % RO Num ND NC PT FI
RW Read / Write RO Read-only Bit Bit parameter Txt Text string Date Date parameter Time Time parameter
Chr Character parameter Bin Binary parameter IP IP address Mac MAC address Ver Version number SMP Slot, menu, parameter
Num Number parameter DE Destination ND
No
default value
RA Rating dependent NC Non-copyable PT Protected
FI Filtered US User save PS
