Deceleration Rate Select Bit 2
(02.037)
Deceleration Rate Select Bit 1
(02.036)
Deceleration Rate Select Bit 0
(02.035)
Deceleration rate
selected
0 0 0
DecelerationRate1
(02.021)
0 0 1
DecelerationRate2
(02.022)
0 1 0
DecelerationRate3
(02.023)
0 1 1
DecelerationRate4
(02.024)
1 0 0
DecelerationRate5
(02.025)
1 0 1
DecelerationRate6
(02.026)
1 1 0
DecelerationRate7
(02.027)
1 1 1
DecelerationRate8
(02.028)
Parameter 02.021 Deceleration Rate 1
Short description Defines the deceleration rate present in deceleration rate 1
Mode Open‑loop
Minimum −VM_ACCEL_RATE Maximum VM_ACCEL_RATE
Default 10.0 Units s
Type 32 Bit User Save Update Rate 16ms
Display Format Standard Decimal Places 1
Coding RW, VM
See RampRateUnits (02.039) for the definition of Ramp rate frequency
DecelerationRate1 (02.021) - DecelerationRate8 (02.028) can be selected to define the linear ramp rate. The deceleration rate applies when the
frequency is changing towards zero.
Selecting a ramp rate that has been set to zero in Asynchronous mode disables the ramp system so that the PostRampReference (02.001) follows the
Pre-rampReference (01.003) without any delay for acceleration or deceleration. It should be noted that this also disables the standard ramp d.c. link
voltage controller and the frequency based current limits.
Parameter 02.022 Deceleration Rate 2
Short description Defines the deceleration rate present in deceleration rate 2
Mode Open‑loop
Minimum −VM_ACCEL_RATE Maximum VM_ACCEL_RATE
Default 10.0 Units s
Type 32 Bit User Save Update Rate 16ms
Display Format Standard Decimal Places 1
Coding RW, VM
See DecelerationRate1 (02.021).
Parameter 02.023 Deceleration Rate 3
Short description Defines the deceleration rate present in deceleration rate 3
Mode Open‑loop
Minimum −VM_ACCEL_RATE Maximum VM_ACCEL_RATE
Default 10.0 Units s
Type 32 Bit User Save Update Rate 16ms
Display Format Standard Decimal Places 1
Coding RW, VM
See DecelerationRate1 (02.021).
Parameter 02.024 Deceleration Rate 4
Short description Defines the deceleration rate present in deceleration rate 4
Mode Open‑loop
Minimum −VM_ACCEL_RATE Maximum VM_ACCEL_RATE
Default 10.0 Units s
Type 32 Bit User Save Update Rate 16ms
Display Format Standard Decimal Places 1
Coding RW, VM
See DecelerationRate1 (02.021).
