Value Text
1 OPEn.LP
2 RFC-A
DriveMode (11.084) is used to hold the currently active drive mode.
Parameter 11.085 Security Status
Short description Displays the security status within the drive
Mode Open‑loop
Minimum 0 Maximum 3
Default Units
Type 8 Bit Power Down Save Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, TE, ND, NC, PT
Value Text
0 None
1 r.only.A
2 Status
3 no.acc
SecurityStatus (11.085) shows the security that will apply when security is enabled by setting a non-zero value for UserSecurityCode (11.030).
Parameter 11.086 Menu Access Status
Short description Displays the amount of access of the menus within the drive
Mode Open‑loop
Minimum 0 Maximum 2
Default Units
Type 8 Bit Power Down Save Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, TE, ND, NC, PT
Value Text
0 LEVEL.1
1 LEVEL.2
2 ALL
If MenuAccessStatus (11.086) = 0 then only parameters up to 10 can be accessed in Menu 0 with a keypad. If MenuAccessStatus (11.086) = 1
then only parameters in Menu 0 can be accessed with a keypad. If MenuAccessStatus (11.086) = 2 then all menus can be accessed with a keypad.
Parameter 11.091 Additional Identifier Characters 1
Short description Displays the additional identifier characters
Mode Open‑loop
Minimum -2147483648 Maximum 2147483647
Default Units
Type 32 Bit Volatile Update Rate Power-up write
Display Format String Decimal Places 0
Coding RO, ND, NC, PT
See ProductIdentifierCharacters (11.064).
Parameter 11.092 Additional Identifier Characters 2
Short description Displays the additional identifier characters
Mode Open‑loop
Minimum -2147483648 Maximum 2147483647
Default Units
Type 32 Bit Volatile Update Rate Power-up write
Display Format String Decimal Places 0
Coding RO, ND, NC, PT
See ProductIdentifierCharacters (11.064).
188
Unidrive M200 Parameter Reference Guide
Issue: 01.05.00.10
