Emerson unidrive m200 - Date;Time Selector; Date Format; Time between Filter Changes; Filter Change Required; Change Done

Parameter 06.019 Date/Time Selector
Short description Defines which clock is used to display the current time, date and day of the week
Mode Open‑loop
Minimum 0 Maximum 6
Default 1 Units
Type 8 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW, TE
Value Text
0 Set
1 Po.up
2 Run
3 Acc.Po
5 Re.Pad
6 Slot.1
Date/TimeSelector (06.019) is used to select the drive date and time as shown in the table below.
Date/Time Selector
(06.019)
Date/Time source
0: Set Date and time parameters can be written by the user
1: Power Time since the drive was powered up
2: Running Accumulated drive running time since the drive was manufactured
3: Acc Power Accumulated powered-up time since the drive was manufactured
4: Local Keypad Reserved
5: Remote Keypad
If a keypad connected to the user comms port of a drive with a 485 port includes a real-time clock then the date/time from
this clock is displayed, otherwise the date/time is set to zero
6: Slot 1
If an option module fitted to the drive contains a real-time clock then the date/time from this clock is displayed, otherwise
the date/time is set to zero.
When Date/TimeSelector (06.019) = 0 the Date (06.016) and Time (06.017) can be written by the user and the values in these parameters are transferred to the real time clocks in the keypad
or any option modules that support this feature that are fitted to the drive. When Date/TimeSelector (06.019) is changed to any other value, the real time clocks are allowed to run normally
again. When Date/TimeSelector (06.019) is changed from any value to 0 the date and time from a real time clock, if present, is automatically loaded into Date (06.016) and Time (06.017), so
that this date and time is used as the initial value for editing. If more than one real time clock is present the date/time from the remote keypad is used, if present, and if not then the date/time
from the option module slot.
Date (06.016) and Time (06.017) are used by the timers in Menu 09 and for time stamping trips. These features will continue to use the originally selected clock even if Date/TimeSelector
(06.019) is changed until a drive reset is initiated. If Date/TimeSelector (06.019) has been changed and a reset is initiated Timer1RepeatFunction (09.039) and Timer2RepeatFunction
(09.049) are set to zero to disable the timers, and the trip dates and times (10.041 to 10.060) are reset to zero.
Parameter 06.020 Date Format
Short description Defines if the US date format is used or not
Mode Open‑loop
Minimum 0 Maximum 1
Default 0 Units
Type 8 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW, TE
Value Text Description
0 Std Standard date format dd.mm.yy
1 US US date format mm.dd.yy
DateFormat (06.020) selects the display style for Date (06.016), Timer1StartDate (09.035), Timer1StopDate (09.037), Timer2StartDate (09.045), Timer2StopDate (09.047) and for the
trip time stamping date parameters ( Trip0Date (10.041), Trip1Date (10.043), Trip2Date (10.045), Trip3Date (10.047), Trip4Date (10.049), Trip5Date (10.051), Trip6Date (10.053),
Trip7Date (10.055), Trip8Date (10.057), Trip9Date (10.059)) when displayed on a keypad connected to the drive. The format selection made in this parameter does not affect the value of
these parameters if they are read using comms or by a user program.
If DateFormat (06.020) is 0 then standard format is used and the date is displayed on the keypad as dd.mm.yy and if DateFormat (06.020) is 1 then US format is used and the date is
displayed on the keypad as mm.dd.yy.
Parameter 06.021 Time Between Filter Changes
Short description Defines the time between filter changes
Mode Open‑loop
Minimum 0 Maximum 30000
Default 0 Units Hours
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW
TimeBetweenFilterChanges (06.021) should be set to a non-zero value to enable the filter change timer system. Each time FilterChangeRequired/ChangeDone (06.022) is changed by the
user from 1 to 0 the value of TimeBetweenFilterChanges (06.021) is copied to TimeBeforeFilterChangeDue (06.023). For each hour while DriveActive (10.002) = 1 the
TimeBeforeFilterChangeDue (06.023) is reduced by 1 until it reaches zero. When TimeBeforeFilterChangeDue (06.023) changes from 1 to 0 FilterChangeRequired/ChangeDone
(06.022) is set to 1 to indicate that a filter change is required. The filter should be changed and the system reset again by resetting FilterChangeRequired/ChangeDone (06.022) to 0.
Parameter 06.022 Filter Change Required / Change Done
Short description Set to 0 when a filter change has taken place
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate Background read/write
Display Format Standard Decimal Places 0
Coding RW, ND, NC
See TimeBetweenFilterChanges (06.021).
90
Unidrive M200 Parameter Reference Guide
Issue: 01.05.00.10
