Emerson unidrive m200 Parameter Reference Guide

Parameter 08.001 Digital I/O 1 State
Short description Displays the state for digtial input/output1
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 1ms
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
DigitalI/O1State (08.001) represents the digital input/output 1 state whether it is a digital input or an output.
If DigitalI/O01mode (08.031) = 0 then it is a digital input:
Comply with IEC 61131-2. Positive logic only.
DigitalI/O1State (08.001) = 0 if the digital I/O is low (<9V)
DigitalI/O1State (08.001) = 1 if the digital I/O is high (>11V).
If DigitalI/O01mode (08.031) = 1 then it is a digital output:
100mA total current including +24Vout; (50mA max per output).
Positive logic only (with 6-7kΩ pull down).
DigitalI/O1State (08.001) = 0 if the source parameter value less than 50% of its range.
DigitalI/O1State (08.001) = 1 if the source parameter value more than 50% of its range.
If DigitalI/O01mode (08.031) = 2 then it is a frequency output (see FrequencyOutputorPWMOutputScaling (03.037) and MaximumOutputFrequency (03.038) for scaling and maximum output frequency
options ).
If DigitalI/O01mode (08.031) = 3 then it is a PWM output (see FrequencyOutputorPWMOutputScaling (03.037) and MaximumOutputFrequency (03.038) for scaling and maximum output frequency options
).
Parameter 08.002 Digital I/O 2 State
Short description Displays the state for digtial input/output 2
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 1ms
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
DigitalI/O2State (08.002) represents the digital input 2 state.
Comply with IEC 61131-2. Positive logic only.
DigitalI/O2State (08.002) = 0 if the digital input is low (<9V)
DigitalI/O2State (08.002) = 1 if the digital input is high (>11V).
Parameter 08.003 Digital Input 3 State
Short description Displays the state for digtial input 3
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 1ms
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
DigitalInput3State (08.003) represents the digital input 3 state.
Comply with IEC 61131-2. Positive logic only.
DigitalInput3State (08.003) = 0 if the digital input is low (<9V)
DigitalInput3State (08.003) = 1 if the digital input is high (>11V).
Parameter 08.004 Digital Input 4 State
Short description Displays the state for digtial input 4
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 1ms
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
DigitalInput4State (08.004) represents the digital input 4 state.
Comply with IEC 61131-2. Positive logic only.
DigitalInput4State (08.004) = 0 if the digital input is low (<9V)
DigitalInput4State (08.004) = 1 if the digital input is high (>11V).
Parameter 08.005 Digital Input 5 State
Short description Displays the state for digtial input 5
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate 1ms
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
DigitalInput5State (08.005) represents the digital input 5 state if Digitalinput5mode (08.035) = 0.
Comply with IEC 61131-2. Positive logic only.
DigitalInput5State (08.005) = 0 if the digital input is low (<9V)
DigitalInput5State (08.005) = 1 if the digital input is high (>11V).
This input can also be used as a thermistor input, or as a frequency input see parameter Digitalinput5mode (08.035).
114
Unidrive M200 Parameter Reference Guide
