Menu 12 Single Line Descriptions − User Functions 2 and Brake Control
Mode: Open‑loop
Parameter Range Default Type
12.001 Threshold Detector 1 Output Off (0) or On (1) RO Bit ND NC PT
12.002 Threshold Detector 2 Output Off (0) or On (1) RO Bit ND NC PT
12.003 Threshold Detector 1 Source 0.000 to 30.999 0.000 RW Num PT US
12.004 Threshold Detector 1 Level 0.00 to 100.00 % 0.00 % RW Num US
12.005 Threshold Detector 1 Hysteresis 0.00 to 25.00 % 0.00 % RW Num US
12.006 Threshold Detector 1 Output Invert Off (0) or On (1) Off (0) RW Bit US
12.007 Threshold Detector 1 Destination 0.000 to 30.999 0.000 RW Num DE PT US
12.008 Variable Selector 1 Source 1 0.000 to 30.999 0.000 RW Num PT US
12.009 Variable Selector 1 Source 2 0.000 to 30.999 0.000 RW Num PT US
12.010 Variable Selector 1 Mode
0 (0), 1 (1), 2 (2), 3 (3), 4 (4),
5 (5), 6 (6), 7 (7), 8 (8), 9 (9)
0 (0) RW Txt US
12.011 Variable Selector 1 Destination 0.000 to 30.999 0.000 RW Num DE PT US
12.012 Variable Selector 1 Output ±100.00 % RO Num ND NC PT
12.013 Variable Selector 1 Source 1 Scaling ±4.000 1.000 RW Num US
12.014 Variable Selector 1 Source 2 Scaling ±4.000 1.000 RW Num US
12.015 Variable Selector 1 Control 0.00 to 100.00 0.00 RW Num US
12.016 Variable Selector 1 Enable Off (0) or On (1) On (1) RW Bit US
12.023 Threshold Detector 2 Source 0.000 to 30.999 0.000 RW Num PT US
12.024 Threshold Detector 2 Level 0.00 to 100.00 % 0.00 % RW Num US
12.025 Threshold Detector 2 Hysteresis 0.00 to 25.00 % 0.00 % RW Num US
12.026 Threshold Detector 2 Output Invert Off (0) or On (1) Off (0) RW Bit US
12.027 Threshold Detector 2 Destination 0.000 to 30.999 0.000 RW Num DE PT US
12.028 Variable Selector 2 Source 1 0.000 to 30.999 0.000 RW Num PT US
12.029 Variable Selector 2 Source 2 0.000 to 30.999 0.000 RW Num PT US
12.030 Variable Selector 2 Mode
0 (0), 1 (1), 2 (2), 3 (3), 4 (4),
5 (5), 6 (6), 7 (7), 8 (8), 9 (9)
0 (0) RW Txt US
12.031 Variable Selector 2 Destination 0.000 to 30.999 0.000 RW Num DE PT US
12.032 Variable Selector 2 Output ±100.00 % RO Num ND NC PT
12.033 Variable Selector 2 Source 1 Scaling ±4.000 1.000 RW Num US
12.034 Variable Selector 2 Source 2 Scaling ±4.000 1.000 RW Num US
12.035 Variable Selector 2 Control 0.00 to 100.00 0.00 RW Num US
12.036 Variable Selector 2 Enable Off (0) or On (1) On (1) RW Bit US
12.040 Off (0) or On (1) RO Bit ND NC PT
12.041 BC Enable
diS (0), Relay (1), dig IO (2),
User (3)
diS (0) RW Txt US
12.042 BC Upper Current Threshold 0 to 200 % 50 % RW Num US
12.043 BC Lower Current Threshold 0 to 200 % 10 % RW Num US
12.044 BC Brake Release Frequency 0.00 to 20.00 Hz 1.00 Hz RW Num US
12.045 BC Brake Apply Frequency 0.00 to 20.00 Hz 2.00 Hz RW Num US
12.046 BC Brake Release Delay 0.0 to 25.0 s 1.0 s RW Num US
12.047 BC Post‑brake Release Delay 0.0 to 25.0 s 1.0 s RW Num US
12.050 BC Initial Direction Ref (0), For (1), Rev (2) Ref (0) RW Txt US
12.051 BC Brake Apply Through Zero Threshold 0.00 to 20.00 Hz 1.00 Hz RW Num US
RW Read / Write RO Read-only Bit Bit parameter Txt Text string Date Date parameter Time Time parameter
Chr Character parameter Bin Binary parameter IP IP address Mac MAC address Ver Version number SMP Slot, menu, parameter
Num Number parameter DE Destination ND
No
default value
RA Rating dependent NC Non-copyable PT Protected
FI Filtered US User save PS
Power-
down save
Unidrive M200 Parameter Reference Guide
Issue: 01.05.00.10
191
