Parameter 10.060 Trip 9 Time
Short description Shows the time at which trip 9 occurred
Mode Open‑loop
Minimum
0
(Display: 00:00:00)
Maximum
235959
(Display: 23:59:59)
Default Units
Type 32 Bit Power Down Save Update Rate Write on trip
Display Format Time Decimal Places 0
Coding RO, ND, NC, PT
See Trip0 (10.020).
Parameter 10.061 Braking Resistor Resistance
Short description Set to the resistance value of the braking resistor
Mode Open‑loop
Minimum 0.00 Maximum 10000.00
Default 0.00 Units Ω
Type 32 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 2
Coding RW
See BrakingResistorRatedPower (10.030).
Parameter 10.064 Remote Keypad Battery Low
Short description Indicates that the real time clock battery in the remote keypad is low
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
RemoteKeypadBatteryLow (10.064) is set to one when a keypad is connected to the drive user comms port with an internal real-time clock and the battery is not
fitted or the voltage is below the minimum threshold.
Parameter 10.065 Auto-tune Active
Short description Indicates that an auto-tune sequence is active
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
Auto-tuneActive (10.065) is set to one while an auto-tune sequence is active.
Parameter 10.066 Limit switch active
Short description Indicates that a limit switch is enabled and active
Mode Open‑loop
Minimum 0 Maximum 1
Default Units
Type 1 Bit Volatile Update Rate Background write
Display Format Standard Decimal Places 0
Coding RO, ND, NC, PT
Limitswitchactive (10.066) is set to one when a limit switch is enabled and active.
Parameter 10.068 Hold Drive Healthy on Under Voltage
Short description Set to hold drive healthy if the drive is in the under voltage state
Mode Open‑loop
Minimum 0 Maximum 1
Default 0 Units
Type 1 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW
HoldDriveHealthyonUnderVoltage (10.068) can be used to hold the drive healthy active (DriveHealthy (10.001) = 1 and not flash the status LED on the front of
the drive) when the drive is in the under voltage state (UnderVoltageActive (10.016) = 1).
If HoldDriveHealthyonUnderVoltage (10.068) = 0 and UnderVoltageActive (10.016) = 1, then DriveHealthy (10.001) will be set to 0 and the status LED on the
front of the drive will flash.
If HoldDriveHealthyonUnderVoltage (10.068) = 1, UnderVoltageActive (10.016) = 1 and the drive is not tripped (i.e. DriveStatus (10.101) does not equal 9), then
DriveHealthy (10.001) will be set to 1 and the status LED on the front of the drive will not flash.
If the drive is tripped then DriveHealthy (10.001) will be set to 0 and the status LED will flash independent of what HoldDriveHealthyonUnderVoltage (10.068) is
set to.
