Menu 2 Single Line Descriptions − Frequency Ramps
Mode: Open‑loop
Parameter Range Default Type
02.001 Post Ramp Reference ±VM_SPEED_FREQ_REF Hz RO Num ND NC PT
02.003 Ramp Hold Off (0) or On (1) Off (0) RW Bit US
02.004 Ramp Mode Select
Fast (0), Std (1), Std.bst (2),
Fst.bst (3)
Std (1) RW Txt US
02.006 S Ramp Enable Off (0) or On (1) Off (0) RW Bit US
02.007 Max Rate Of Change Of Acceleration 0.0 to 300.0 s²/100Hz 3.1 s²/100Hz RW Num US
02.008 Standard Ramp Voltage ±VM_DC_VOLTAGE_SET V
110V drive: 375 V
200V drive: 375 V
400V drive 50Hz: 750 V
400V drive 60Hz: 775 V
575V drive: 895 V
690V drive: 1075 V
RW Num RA US
02.009 Deceleration Fail Detection Disable Off (0) or On (1) Off (0) RW Bit US
02.010 Acceleration Rate Selector 0 to 9 0 RW Num US
02.011 Acceleration Rate 1 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.012 Acceleration Rate 2 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.013 Acceleration Rate 3 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.014 Acceleration Rate 4 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.015 Acceleration Rate 5 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.016 Acceleration Rate 6 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.017 Acceleration Rate 7 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.018 Acceleration Rate 8 ±VM_ACCEL_RATE s 5.0 s RW Num US
02.019 Jog Acceleration Rate ±VM_ACCEL_RATE s 0.2 s RW Num US
02.020 Deceleration Rate Selector 0 to 9 0 RW Num US
02.021 Deceleration Rate 1 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.022 Deceleration Rate 2 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.023 Deceleration Rate 3 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.024 Deceleration Rate 4 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.025 Deceleration Rate 5 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.026 Deceleration Rate 6 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.027 Deceleration Rate 7 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.028 Deceleration Rate 8 ±VM_ACCEL_RATE s 10.0 s RW Num US
02.029 Jog Deceleration Rate ±VM_ACCEL_RATE s 0.2 s RW Num US
02.030 Acceleration Rate Selected 0 to 8 RO Num ND NC PT
02.031 Deceleration Rate Selected 0 to 8 RO Num ND NC PT
02.032 Acceleration Rate Select Bit 0 Off (0) or On (1) Off (0) RW Bit NC
02.033 Acceleration Rate Select Bit 1 Off (0) or On (1) Off (0) RW Bit NC
02.034 Acceleration Rate Select Bit 2 Off (0) or On (1) Off (0) RW Bit NC
02.035 Deceleration Rate Select Bit 0 Off (0) or On (1) Off (0) RW Bit NC
02.036 Deceleration Rate Select Bit 1 Off (0) or On (1) Off (0) RW Bit NC
02.037 Deceleration Rate Select Bit 2 Off (0) or On (1) Off (0) RW Bit NC
02.039 Ramp Rate Units 0 to 2 0 RW Num US
02.040 S Ramp Percentage 0.0 to 50.0 % 0.0 % RW Num US
02.041 S Ramp Set‑up Mode 0 to 2 0 RW Num US
02.042 Maximum Rate Of Change Of Acceleration 1 0.0 to 300.0 s²/100Hz 0.0 s²/100Hz RW Num US
02.043 Maximum Rate Of Change Of Acceleration 2 0.0 to 300.0 s²/100Hz 0.0 s²/100Hz RW Num US
02.044 Maximum Rate Of Change Of Acceleration 3 0.0 to 300.0 s²/100Hz 0.0 s²/100Hz RW Num US
02.045 Maximum Rate Of Change Of Acceleration 4 0.0 to 300.0 s²/100Hz 0.0 s²/100Hz RW Num US
RW Read / Write RO Read-only Bit Bit parameter Txt Text string Date Date parameter Time Time parameter
Chr Character parameter Bin Binary parameter IP IP address Mac MAC address Ver Version number SMP Slot, menu, parameter
Num Number parameter DE Destination ND
No
default value
RA Rating dependent NC Non-copyable PT Protected
FI Filtered US User save PS
Power-
down save
