If a KTY84, PT1000 or PT2000 type device is selected for temperature feedback (i.e. ThermistorType (07.046) = 1 to 3) then ThermistorTemperature (07.050) shows the temperature of the
device based on the resistance to temperature characteristic specified for this device. Otherwise ThermistorTemperature (07.050) = 0.0.
Parameter 07.051 Analog Input 1 Control
Short description Defines the functionality of analog input 1
Mode Open‑loop
Minimum 0 Maximum 5
Default 0 Units
Type 8 Bit User Save Update Rate Drive reset read
Display Format Standard Decimal Places 0
Coding RW
Value Description
Analog Input 1 Destination B
(07.090)
0
User defined by AnalogInput1DestinationA
(07.010)
00.000
1 Frequency reference 1 01.036
2 Frequency reference 2 01.037
3 Maximum reference clamp 01.006
4 Current limit 04.007
5 Torque reference 04.008
This offers a simple control of parameter AnalogInput1DestinationB (07.090) to change the analog input 1 functionality.
If AnalogInput1Control (07.051) is more than 0 then the destination is defined by AnalogInput1DestinationB (07.090). The destination AnalogInput1DestinationB (07.090) is written by
AnalogInput1Control (07.051) selection. (i.e. If AnalogInput1Control (07.051) = 3 then AnalogInput1DestinationB (07.090) = 01.006)
If AnalogInput1Control (07.051) is 0 then then the destination is defined by AnalogInput1DestinationA (07.010).
Parameter 07.052 Analog Input 2 Control
Short description Defines the functionality of analog input 2
Mode Open‑loop
Minimum 0 Maximum 5
Default 0 Units
Type 8 Bit User Save Update Rate Drive reset read
Display Format Standard Decimal Places 0
Coding RW
Value Description
Analog Input 2 Destination B
(07.094)
0
User defined by AnalogInput2DestinationA
(07.014)
00.000
1 Frequency reference 1 01.036
2 Frequency reference 2 01.037
3 Maximum reference clamp 01.006
4 Current limit 04.007
5 Torque reference 04.008
This offers a simple control of parameter AnalogInput2DestinationB (07.094) to change the analog input 2 functionality.
If AnalogInput2Control (07.052) is more than 0 then the destination is defined by AnalogInput2DestinationB (07.094). The destination AnalogInput2DestinationB (07.094) is written by
AnalogInput2Control (07.052) selection. (i.e. If AnalogInput2Control (07.052)= 3 then AnalogInput2DestinationB (07.094) = 01.006)
If AnalogInput2Control (07.052) is 0 then then the destination is defined by AnalogInput2DestinationA (07.014).
Parameter 07.055 Analog Output 1 Control
Short description Defines the functionality of analog output 1
Mode Open‑loop
Minimum 0 Maximum 15
Default 0 Units
Type 8 Bit User Save Update Rate Drive reset read
Display Format Standard Decimal Places 0
Coding RW, BU
Value Description Analog Output 1 Source B (07.099)
0 User defined by AnalogOutput1SourceA (07.019) 00.000
1 Post Ramp frequency reference (0 - ±VM_SPEED_FREQ_REF) 02.001
2 Pre Ramp frequency reference (0 - ±VM_SPEED_FREQ_REF) 01.003
3 Motor speed (0 - ±33,000) 05.004
4 Current output (0 - FullScaleCurrentKc (11.061)) 04.001
5 Reserved Reserved
6 Percentage load (0 - ± UserCurrentMaximumScaling (04.024)) 04.020
7 Torque producing current (0 - FullScaleCurrentKc (11.061)) 04.002
8 Voltage output (0 - VM_AC_VOLTAGE) 05.002
9 DC bus voltage (0 - VM_DC_VOLTAGE) 05.005
10 Analogue Input 1 (0 - ±100%) 07.001
11 Analogue Input 2 (0 - ±100%) 07.002
12 Power output (0 - ±VM_POWER) 05.003
13 Current limit (0 - ±VM_TORQUE_CURRENT) 04.018
14 Torque reference (0 - ±UserCurrentMaximumScaling (04.024)) 04.008
15 Reserved Reserved
This offers a simple control of parameter AnalogOutput1SourceB (07.099) to change the analog output 1 source.
If AnalogOutput1Control (07.055) is more than 0 then the source is defined by AnalogOutput1SourceB (07.099). The source AnalogOutput1SourceB (07.099) is written by
AnalogOutput1Control (07.055) selection. (i.e. If AnalogOutput1Control (07.055) = 13 then AnalogOutput1SourceB (07.099) = 04.018)
If 07.055 is 0 then then the source is defined by AnalogOutput1SourceA (07.019) .
