Region Default Value
50Hz 1500.0
60Hz 1800.0
This is the motor map 2 equivalent for MotorRatedSpeed (05.008).
Parameter 21.009 M2 Motor Rated Voltage
Short description Defines the motor rated voltage used for motor map 2
Mode Open‑loop
Minimum −VM_AC_VOLTAGE_SET Maximum VM_AC_VOLTAGE_SET
Default See exceptions below Units V
Type 16 Bit User Save Update Rate 16ms
Display Format Standard Decimal Places 0
Coding RW, VM, RA
Voltage Region Default Value
110V All 230
200V All 230
400V 50Hz 400
400V 60Hz 460
575V All 575
690V All 690
This is the motor map 2 equivalent for MotorRatedVoltage (05.009).
Parameter 21.010 M2 Motor Rated Power Factor
Short description Defines the motor rated power factor used for motor map 2
Mode Open‑loop
Minimum 0.00 Maximum 1.00
Default 0.85 Units
Type 16 Bit User Save Update Rate Background read/write
Display Format Standard Decimal Places 2
Coding RW, RA
This is the motor map 2 equivalent for MotorRatedPowerFactor (05.010).
Parameter 21.011 M2 Number Of Motor Poles
Short description Defines the number of motor poles used for motor map 2
Mode Open‑loop
Minimum 0 Maximum 16
Default 0 Units Pole pairs
Type 8 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 0
Coding RW, BU
This is the motor map 2 equivalent for NumberOfMotorPoles (05.011).
Parameter 21.012 M2 Stator Resistance
Short description Defines the stator resistance used for motor map 2
Mode Open‑loop
Minimum 0.0000 Maximum 99.9999
Default 0.0000 Units Ω
Type 32 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 4
Coding RW, RA
This is the motor map 2 equivalent for StatorResistance (05.017).
Parameter 21.014 M2 Transient Inductance
Short description Defines the transient inductance used for motor map 2
Mode Open‑loop
Minimum 0.000 Maximum 500.000
Default 0.000 Units mH
Type 32 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 3
Coding RW, RA
This is the motor map 2 equivalent for TransientInductance (05.024).
