Parameter 07.064 Analog Input 1 At Maximum Reference
Short description Defines the value of analog input 1 at maximum reference
Mode Open‑loop
Minimum -100.00 Maximum 100.00
Default 100.00 Units %
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 2
Coding RW
See AnalogInput1MinimumReference (07.061).
Parameter 07.065 Analog Input 2 Minimum Reference
Short description Defines the minimum reference for analog input 2
Mode Open‑loop
Minimum 0.00 Maximum 100.00
Default 0.00 Units %
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 2
Coding RW
See graph in AnalogInput1MinimumReference (07.061).
AnalogInput2 (07.002) can be scaled and limited using the following parameters:
AnalogInput2MinimumReference (07.065)
AnalogInput2AtMinimumReference (07.066)
AnalogInput2MaximumReference (07.067)
AnalogInput2AtMaximumReference (07.068)
Parameters above can be selected to limit the range of AnalogInput2 (07.002) and also scale it between the minimum and maximum reference.
If AnalogInput2MinimumReference (07.065) ≥ AnalogInput2MaximumReference (07.067) then A
i2
= 0.00% whatever the input level.
Input Level is limited between AnalogInput2AtMinimumReference (07.066) and AnalogInput2AtMaximumReference (07.068)
AnalogInput2 (07.002) = [(AnalogInput2AtMaximumReference (07.068) - AnalogInput2AtMinimumReference (07.066))/(AnalogInput2MaximumReference (07.067) -
AnalogInput2MinimumReference (07.065))] x (Input level - AnalogInput2MinimumReference (07.065))+ AnalogInput2AtMinimumReference (07.066).
Parameter 07.066 Analog Input 2 At Minimum Reference
Short description Defines the value of analog input 2 at minimum reference
Mode Open‑loop
Minimum -100.00 Maximum 100.00
Default 0.00 Units %
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 2
Coding RW
See AnalogInput2MinimumReference (07.065).
Parameter 07.067 Analog Input 2 Maximum Reference
Short description Defines the maximum reference for analog input 2
Mode Open‑loop
Minimum 0.00 Maximum 100.00
Default 100.00 Units %
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 2
Coding RW
See AnalogInput2MinimumReference (07.065).
Parameter 07.068 Analog Input 2 At Maximum Reference
Short description Defines the value of analog input 2 at maximum reference
Mode Open‑loop
Minimum -100.00 Maximum 100.00
Default 100.00 Units %
Type 16 Bit User Save Update Rate Background read
Display Format Standard Decimal Places 2
Coding RW
See AnalogInput2MinimumReference (07.065).
Parameter 07.090 Analog Input 1 Destination B
Short description Defines the secondary destination for analog input 1
Mode Open‑loop
Minimum 0.000 Maximum 30.999
Default Units
Type 16 Bit User Save Update Rate Drive reset read
Display Format Standard Decimal Places 3
Coding RO, DE, ND, NC, PT
See AnalogInput1DestinationA (07.010).
