Value Text Description
185 C.Acc Communication failure with NV media card detected
178 C.by NV media card in use
188 C.cPr NV media card data and drive data is not the same
179 C.d.e NV media card data already exists
183 C.dAt Attempt to read non-existant data detected
182 C.Err NV media card data structure error detected
184 C.Ful NV media card is full
180 C.OPt Option difference detected
175 C.Pr Product difference detected
181 C.rdo Attempt to overwrite protected data detected
186 C.rtg Transfer of data between drives of different ratings detected
187 C.Typ
Transfer of data between drives operating in different modes
detected
28 cL.A1 Current loop loss on analog input 1
29 cL.A2 Current loop loss on analog input 2
35 CL.bt Control word trip (bit 12)
231 Cur.c Current feedback calibration range error
97 D.Ch Drive has become active while data is being updated
110 dcct DC Current transformer failure (size 5 and above)
246 Der.E Derivative Image error
248 Der.I Derivative program error
199 dESt
A parameter is being changed by more than 1 routing
destination
232 Dr.Cf Incorrect configuration data
31 EEF Non-volatile memory failure
6 Et External trip generated by the application
173 FaN.f Cooling fan failure
247 Fi.Ch Configuration data within the drive has changed
237 FI.In
The power stage and control board firmware versions are not
compatible
20 It.ac Motor over temperature
19 It.br Brake resistor over temperature
90 LF.Er
Communication link failure in the power stage (size 5 and
above)
236 no.PS No power stage detected by the Control board
0 None No trip recorded
26 O.Ld1 Overload on 24V or digital outputs
7 O.Spd Motor over speed
27 Oh.dc Overload on DC bus components
219 Oht.C Control board over temperature
21 Oht.I Inverter IGBT junction over temperature
22 Oht.P Power stage over temperature
189 OI.A1 Current loop overload on analog input 1
190 OI.A2 Current loop overload on analog input 2
3 OI.aC Over current at the motor terminals
4 OI.br Over current in the brake IGBT
228 OI.E1 Over current on U phase
229 OI.E2 Over current on V phase
230 OI.E3 Over current on W phase
92 OI.Sn Over current in snubber components (size 5 and above)
98 Out.P One of the motor windings is not drawing current
2 OV DC Bus voltage is high
220 P.Dat Configuration data failure
34 Pad Keypad communication failure
245 Pb.bt Power stage processor is in its boot loader
93 Pb.Er
Communication link failure between Control board and power
stage
235 Pb.HF Harware Fault in the power stage processor detected
37 Pd.S Power down saved parameters have been corrupted
32 PH.Lo Input Phase Loss
5 PSU Internal Power Supply fault
227 r.All RAM allocation failure
250 R.b.ht
1 Res
9 Res
10 Res
12 Res
14 Res
15 Res
16 Res
