Frontier LP7500 - Page 286

3. Mode
35210
5/5
35210
Maintenance
!
!!
! Operation of the interlock switches
If the quad magazine unit is installed
If the quad magazine unit is not installed
*1. Printer Door 3 Sensor is shown only when the triple magazine unit is installed.
When each interlock switch
is off
Status of Input Check when each interlock switch is off
Interlock Switch
(Printer Top Cover)
Interlock Switch
(Printer Doors 1, 4)
Interlock Switch
(Printer Door 2)
Printer Door 3 Sensor
Interlock Switch (Printer Top
Cover)
OFF OFF OFF ON
Interlock Switch (Printer Door
1)
ON OFF OFF ON
Interlock Switch (Printer Door
2)
ON ON OFF ON
Printer Door 3 Sensor ON ON ON OFF
Interlock switch (printer door
4)
ON OFF OFF ON
When each interlock switch
is off
Status of Input Check when each interlock switch is off
Interlock Switch
(Printer Top Cover)
Interlock Switch
(Printer Door 1)
Interlock Switch
(Printer Door 2)
Printer Door 3
Sensor
*1
Interlock Switch (Printer Top
Cover)
OFF OFF OFF ON
Interlock Switch (Printer Door
1)
ON OFF OFF ON
Interlock Switch (Printer Door
2)
ON ON OFF ON
Printer Door 3 Sensor
*1
ON ON ON OFF
