4. Troubleshooting
41000
41000
Attention message: Printer
No. 01047
Close printer door.
Attention message release
YES or automatic release
• This attention message will be automatically closed when the printer door is closed.
Condition
NOTE
• If the interlock switch (printer door 1, 2 or 4) turns off, power is not supplied to some electrical parts.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The interlock switch (printer door 1, 2 or 4) turns off.
00002 Printer door 3 sensor turns off.
1 Check that printer doors 1, 2, 3, and 4 are securely closed.
Failed part Manual No.
Interlock switch (printer door 1, 2, 4) ☞63050
Printer door 3 sensor ☞63050
Printer I/O PCB 1
☞66020
Triple magazine PCB ☞66050
Quad magazine PCB ☞66055
Printer control PCB
☞66000
Printer power supply 5 ☞66100
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
