Attention message: Main
1/3
4. Troubleshooting
41900
41900
Attent ion me ssage: Ma in
No. 01920
Capacity Booster Key was not detected. Confirm the connection status.
Attention message release
YES
• Select YES to operate as the low capability type input section.
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00032 When the system starts up, it cannot detect capacity booster F.
00064 When the system starts up, it cannot detect capacity booster G.
00096 When the system starts up, it cannot detect capacity booster PCB F and capacity booster PCB G.
00128 When the system starts up, it cannot detect capacity booster PCB H.
00256 When the system starts up, it cannot detect capacity booster PCB I.
01024 If the option CD for capacity booster F is not installed
02048 If the option CD for capacity booster G is not installed
03072 If the option CD for capacity booster F and G is not installed
04096 If the option CD for capacity booster H is not installed
08192 If the option CD for capacity booster I is not installed
1 Confirm that the capacity booster PCB is recognized correctly.
☞35500
2 Confirm that the booster hard key is attached correctly.
3 Confirm that Capacity Booster Software has been installed normally.
• After installing the Capacity Booster Software, click OK on the Machine Specification display.
4 Confirm the connection between the printer I/F main PCB (J/P1211) and capacity booster PCB (J/P860).
Failed part Manual No.
Capacity booster PCB ☞66008
Printer I/F main PCB
☞66005
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
