4. Troubleshooting
45900
10/16
45900
Error message: F replenishment
No. 05913[F]
An error occurred in the replenisher section.
Error message release
YES
IMPORTANT
• If the above error message is shown, do not click YES to close it and continue the printing process without performing the
diagnosis below.
After a set number of prints are output,
☞No. 05912[F] Predetermined process amount was exceeded. will be shown,
and then printing cannot be performed.
NOTE
• If printing process is continued after the above error is shown, the time is counted as Replenishment Lack Time and the P1R, P2RA
and P2RB replenishers will not be replenished.
Condition
Condition
When an error in the following error list occurred, the system was restarted or started before the error was cleared.
Error list Countermeasure
• ☞No. 05900[F] • Replenisher cartridge open motor operation error. Recovery procedure from the
error(s) shown in the left
•
☞No. 05905[F]
• ☞No. 05906[F]
•
☞No. 05907[F]
• P1R replenishment solution output amount/replenishment solution level
management is abnormal.
• P2RA replenishment solution output amount/replenishment solution
level management is abnormal.
• P2RA replenishment solution output amount/replenishment solution
level management is abnormal.
Recovery procedure from the
error(s) shown in the left
•
☞No. 05908[F] • Failed to open the replenisher cartridge. Recovery procedure from the
error(s) shown in the left
•
☞No. 05909[F]
• ☞No. 05910[F]
• ☞No. 05911[F]
• Cartridge cleaning valve/Agitation solenoid valve is abnormal. P1R
• Cartridge cleaning valve cleaning valve is abnormal. P2RA
• Cartridge cleaning valve cleaning valve is abnormal. P2RB
Recovery procedure from the
error(s) shown in the left
•
☞No. 05913[F] • An error occurred in the replenisher section.
• For the QSS-3701/3702/3703/LP7500/LP7600, about 507 prints whose size is 127 mm × 89 mm can be processed after the error
occurs.
• For the QSS-3704/3705/LP7700/LP7900, about 545 prints whose size is 127 mm × 89 mm can be processed after the error occurs.
Countermeasure
1. See the Error Record, and check which error occurred.
If the EZ Controller is used
Bringing up the display
Controller Main Display: 2260 → Click F. → Management Tool → System management → Error Record
2. Perform the recovery procedure from the error.
