Courier Text Col Row Default Setting Available Options
Description
Alarm Status 3 00 52
0=Battery Fail
1=Field Volt Fail
2=Unused
3=GOOSE IED Absent
4=NIC Not Fitted
5=NIC No Response
6=NIC Fatal Error
7=Unused
8=Unused
9=Unused
10=NIC Link Fail
11=NIC SW Mis-Match
12=IP Addr Conflist
13=Unused
14=Unused
15=Unused
16=Unused
17=Backup Setting
18=Unused
19=Unused
20=Unused
21=Unused
22=Unused
23=Unused
24=Unused
25=Unused
26=Unused
27=Unused
28=Unused
29=Unused
30=Unused
31=Unused
This cell displays the status of the third set of 32 alarms as a binary string, including fixed and user settable alarms.
Access Level 00 D0
0 = Read Some, 1 = Read All, 2 = Read
All + Write Some, 3 = Read All + Write All
This cell displays the current access level.
Password Level
1
00 D2 (8 spaces)
ASCII text (characters 33 to 122
inclusive)
This setting allows you to change password level 1.
Password Level
2
00 D3 BBBB
ASCII text (characters 33 to 122
inclusive)
This setting allows you to change password level 2.
Password Level
3
00 D4 AAAA
ASCII text (characters 33 to 122
inclusive)
This setting allows you to change password level 3.
Security Features 00 DF 1 <cyber security level>
This setting displays the level of cyber security implemented, 1 = phase 1.
Password 00 E1
ASCII text (characters 33 to 122
inclusive)
This cell allows you to enter the encrypted password. It is not visible via the user interfaced.
Password Level
1
00 E2
ASCII text (characters 33 to 122
inclusive)
This setting allows you to change the encrypted password level 1. This is not visible via the user interface.
Chapter 4 - Configuration MiCOM P747
82 P747-TM-EN-1
P747-TM-EN-1.1
