16 COMMUNICATION SETTINGS
This section contains a complete table of the settings required to set up the device communication.
Courier Text Col Row Default Setting Available Options
Description
COMMUNICATIONS 0E 00
This column contains settings for configuring the communications
RP1 Protocol 0E 01
0 = Courier,
1 = IEC870-5-103,
2 = Modbus,
3 = DNP3.0
This cell displays the communications protocol that is used on RP1.
RP1 Address 0E 02 255 0 to 255 (Courier)
This sets the Rear Port 1 Courier Protocol device address
RP1 Address 0E 02 1 0 to 247 (Modbus)
This sets the Rear Port 1 Modbus Protocol device address
RP1 Address 0E 02 1 0 to 254 (CS103)
This sets the Rear Port 1 IEC60870-5-103 Protocol device address
RP1 Address 0E 02 1 0 to 65534 (DNP3.0)
This sets the Rear Port 1 DNP 3.0 Protocol device address
RP1 InactivTimer 0E 03 15 From 1 min to 30 min step 1m
This sets the Rear Port 1 Courier Protocol inactivity timer
RP1 InactivTimer 0E 03 15 From 1 min to 30 min step 1m
This sets the Rear Port 1 Modbus Protocol inactivity timer
RP1 InactivTimer 0E 03 15 From 1 min to 30 min step 1m
This sets the Rear Port 1 IEC60870-5-103 Protocol inactivity timer
RP1 Baud Rate 0E 04 19200 bits/s
1200, 2400, 4800 9600, 19200, 38400
(dependent on protocol)
This sets the Rear Port 1 Modbus Protcol serial bit/baud rate
RP1 Baud Rate 0E 04 19200 bits/s
1200, 2400, 4800 9600, 19200, 38400
(dependent on protocol)
This sets the Rear Port 1 IEC60870-5-103 Protcol serial bit/baud rate
RP1 Baud Rate 0E 04 19200 bits/s
1200, 2400, 4800 9600, 19200, 38400
(dependent on protocol)
This sets the Rear Port 1 DNP 3.0 Protcol serial bit/baud rate
RP1 Parity 0E 05 None 0 = Odd, 1 = Even, 2 = None
This sets the Rear Port 1 Modbus Protocol parity
RP1 Parity 0E 05 None 0 = Odd, 1 = Even, 2 = None
This sets the Rear Port 1 DNP 3.0 Protocol parity
RP1 Meas Period 0E 06 15 From 1s to 60s step 1s
This sets the Rear Port 1 IEC60870-5-103 Protocol measurment period
RP1 PhysicalLink 0E 07 Copper 0 = Copper or 1 = Fibre Optic
This sets the Rear Port 1 Physical link selector. Available when Fibre Optic Comms card is specified by model number
RP1 Time Sync 0E 08 Disabled 0 = Disabled or 1 = Enabled
This sets the Rear Port 1 DNP 3.0 Protocol time sync configuration. NB Not available when IRIG-B option fitted and
enabled.
