9 MODBUS
This section describes how the MODBUS standard is applied to the Px40 platform. It is not a description of
the standard itself. The level at which this section is written assumes that the reader is already familiar with
the MODBUS standard.
The MODBUS protocol is a master/slave protocol, defined and administered by the MODBUS Organization
For further information on MODBUS and the protocol specifications, please seethe Modbus web site
(www.modbus.org).
9.1 PHYSICAL CONNECTION AND LINK LAYER
Two connection options are available for MODBUS
Rear Port 1 (RP1) - for permanent SCADA connection via RS485
Optional fibre port (RP1 in slot A) - for permanent SCADA connection via optical fibre
The MODBUS interface uses ‘RTU’ mode communication rather than ‘ASCII’ mode as this provides more
efficient use of the communication bandwidth. This mode of communication is defined by the MODBUS
standard.
The IED address and baud rate can be selected using the front panel menu or by the settings application
software.
When using a serial interface, the data format is: 1 start bit, 8 data bits, 1 parity bit with 1 stop bit, or 2 stop
bits (a total of 11 bits per character).
9.2 MODBUS FUNCTIONS
The following MODBUS function codes are supported:
01: Read Coil Status
02: Read Input Status
03: Read Holding Registers
04: Read Input Registers
06: Preset Single Register
08: Diagnostics
11: Fetch Communication Event Counter
12: Fetch Communication Event Log
16: Preset Multiple Registers 127 max
These are interpreted by the MiCOM IED in the following way:
01: Read status of output contacts (0xxxx addresses)
02: Read status of opto inputs (1xxxx addresses)
03: Read setting values (4xxxx addresses)
04: Read measured values (3xxxx addresses
06: Write single setting value (4xxxx addresses)
16: Write multiple setting values (4xxxx addresses)
9.3 RESPONSE CODES
MCode MODBUS Description MiCOM Interpretation
01 Illegal Function Code The function code transmitted is not supported by the slave.
Chapter 7 - SCADA Communications MiCOM P747
210 P747-TM-EN-1
P747-TM-EN-1.1
