Courier Text Col Row Default Setting Available Options
Description
MEASURE'T
SETUP
0D 00
This column contains settings for the measurement setup
Default Display 0D 01 User Banner
0 Banner
1 Date and Time
2 Description
3 Plant Reference
4 Frequency
5 Access Level
This setting is used to select the default display from a range of options.
Local Values 0D 02 Primary 0 = Primary or 1 = Secondary
This setting controls whether local measured values (via HMI or front port) are displayed as primary or secondary
quantities.
Remote Values 0D 03 Primary 0 = Primary or 1 = Secondary
This setting controls whether remote measured values (via rear comms ports) are displayed as primary or secondary
quantities.
Measurement Ref 0D 04 VXN Z1
0 VxN Z1
1 VxN Z2
2 VxN Z3
3 VxN Z4
4 IX-T1
5 IX-T2
6 IX-T3
7 IX-T4
8 IX-T5
9 IX-T6
10 IX-T7
11 IX-T8
12 IX-T9
13 IX-T10
14 IX-T11
15 IX-T12
16 IX-T13
17 IX-T14
18 IX-T15
19 IX-T16
20 IX-T17
21 IX-T18
This sets the phase reference for all angular measurements (for Measurements 1 only).
4.3 MEASUREMENT TABLES
Courier Text Col Row Default Setting Available Options
Description
MEASUREMENTS
1
02 00
This column contains measurement parameters
IX-1 Magnitude 02 25 Not Settable
IX-1 Magnitude
IX-1 Phase Angle 02 26 Not Settable
IX-1 Phase Angle
Chapter 6 - Monitoring and Control MiCOM P747
164 P747-TM-EN-1
P747-TM-EN-1.1
