Courier Text Col Row Default Setting Available Options
Description
DST Start Month 08 26 March
0 = January, 1 = February, 2 = March, 3
= April, 4 = May, 5 = June, 6 = July, 7 =
August, 8 = September, 9 = October, 10
= November or 11 = December
This setting specifies the month in which daylight saving time adjustment starts
DST Start Mins 08 27 60 From 0 mins to 1425 mins step 15 mins
Setting to specify the time of day in which daylight saving time adjustment starts. This is set relative to 00:00 hrs on the
selected day when time adjustment is to start
DST End 08 28 Last
0 = First, 1 = Second, 2 = Third, 3 =
Fourth or 4 = Last
This setting specifies the week of the month in which daylight saving time adjustment ends
DST End Day 08 29 Sunday
0 = Sunday, 1 = Monday, 2 = Tuesday,
3 = Wednesday, 4 = Thursday, 5 =
Friday or 6 = Saturday
This setting specifies the day of the week in which daylight saving time adjustment ends.
DST End Month 08 2A October
0 = January, 1 = February, 2 = March, 3
= April, 4 = May, 5 = June, 6 = July, 7 =
August, 8 = September, 9 = October, 10
= November or 11 = December
This setting specifies the month in which daylight saving time adjustment ends.
DST End Mins 08 2B 60 From 0m to 1425m step 15m
This setting specifes the time of day in which daylight saving time adjustment ends. This is set relative to 00:00 hrs on
the selected day when time adjustment is to end.
RP1 Time Zone 08 30 UTC 0 = UTC or 1 = Local
Setting for the rear port 1 interface to specify if time synchronization received will be local or universal time co-
ordinated.
RP2 Time Zone 08 31 UTC 0 = UTC or 1 = Local
Setting for the rear port 2 interface to specify if time synchronization received will be local or universal time co-ordinated
DNPOE Time
Zone
08 32 UTC 0 = UTC or 1 = Local
This setting specifies whether DNP3.0 over Ethernet time synchronisation is coordinated by local time or universal time.
Tunnel Time Zone 08 33 UTC 0 = UTC or 1 = Local
This setting specifies whether tunnelled Courier time synchronisation is coordinated by local time or universal time.
5.3 GENERAL CONFIGURATION
Courier Text Col Row Default Setting Available Options
Description
CONFIGURATION 09 00
This column contains the general configuration options
Restore Defaults 09 01 No Operation
0 = No Operation, 1 = All Settings, 2
= Setting Group 1, 3 = Setting Group
2, 4 = Setting Group 3, 5 = Setting
Group 4
This setting restores the chosen setting groups to factory default values. Note: Restoring defaults to all settings includes
the rear communication port settings, which may result in communication via the rear port being disrupted if the new
(default) settings do not match those of the master station.
Chapter 4 - Configuration MiCOM P747
84 P747-TM-EN-1
