Courier Text Col Row Default Setting Available Options
Description
Secondary 0A 4B 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 16 CT 0A 4C
This sets CT main data
Polarity 0A 4D Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 4E 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 4F 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 17 CT 0A 50
This sets CT main data
Polarity 0A 51 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 52 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 53 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 18 CT 0A 54
This sets CT main data
Polarity 0A 55 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 56 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 57 1 From to step
Sets the phase Current Transformer input secondary current rating
5.5 SYSTEM CONFIGURATION
Courier Text Col Row Default Setting Available Options
Description
GROUP 1
SYSTEM CONFIG
30 00
This column contains the general configuration options
Protected Phase 30 31 Phase A Phase A, Phase B, Phase C
This defines the phase to be protected
Feeder Numbers 30 33 8 From to step
This defines the feeder number
Chapter 4 - Configuration MiCOM P747
90 P747-TM-EN-1
P747-TM-EN-1.1
