Wavewin provides the following functions.
● File management
● Query management
● Log management
● Report generation
● Sequence of Events(SOE)
● Conversion of COMTRADE files
● Waveform summary
1.10 DEVICE (MENU) TEXT EDITOR
The Menu Text Editor enables you to modify and replace the menu texts held in MiCOM Px4x IEDs. For
example, you may want to customise an IED so that menus appear in a language other than one of the
standard languages.
By loading a copy of the current menu text file in one of the standard languages into the reference column,
you can type the appropriate translation of each menu entry into the target column.
This can then be sent from the PC to the IED, replacing one of the current standard languages. New menu
text files created this way can also be saved to disk for later use or further editing.
1.11 EVENT VIEWER
IEDs record all events in an event log. This allows you to establish the sequence of events that led up to a
particular situation. For example, a change in a digital input signal or protection element output signal would
cause an event record to be created and stored in the event log. This could be used to analyse how a
particular power system condition was caused.
When available space is exhausted, the oldest event is overwritten by the new one. The IED's internal clock
provides a time tag for each event.
The event records can be displayed on an IED's front panel but it is easier to view them through the settings
application software. This can extract the events log from the device and store it as a single .evt file for
analysis on a PC.
1.12 GOOSE EDITOR
Using the GOOSE Editor you can edit the UCA2 GOOSE settings for a MiCOM Px4x series IED. You can
also map GOOOSE inputs and outputs to the DDB signals of an IED.
The GOOSE Editor can extract settings from and send settings to an IED using a Courier port on the IED. It
can also save IED settings to a file on your PC or print them.
1.13 PRP CONFIGURATOR
The PRP Configurator tool is intended for MiCOM Px4x IEDs with redundant Ethernet using PRP (Parallel
Redundancy Protocol). This tool is used to identify IEDs, configure the redundancy IP address, configure the
SNTP IP address and configure the PRP parameters.
1.14 RSTP CONFIGURATOR
The RSTP Configurator tool is intended for MiCOM Px4x IEDs with redundant Ethernet using RSTP (Rapid
Spanning Tree Protocol). This tool is used to identify IEDs, configure the redundancy IP address, configure
the SNTP IP address and configure the RSTP parameters.
Chapter 10 - Settings Application Software MiCOM P747
300 P747-TM-EN-1
