2.3.1 ADD A LABEL TO AN ELEMENT
To add a label to an element:
1.
Double-click the element and select a label from the drop-down list.
If many labels are available it can sometimes be difficult to find a specific one from the drop-down list.
A search function helps you to find the one you need.
2. Double-click the element.
3. Enter the seach text in the box at the top of the drop-down list.
2.3.2 REMOVE A LABEL FROM AN ELEMENT
To remove a label from an element, right-click the element and select Remove Label.
2.3.3 CHANGE AN ELEMENT'S LABEL
To change the label of an element, right-click the element and select Edit Label.
2.3.4 ADD OR REMOVE FREE TEXT
To add or remove free text, drag and drop the Free Text object onto the scheme and enter the text.
To edit the text, double click it.
To remove the text block, right-click it and select Remove.
2.3.5 VALIDATE A SCHEME
This checks for potential errors in the scheme and makes suggestions of how to correct them.
To validate scheme elements and the connections between them, click the Validate icon. To display the
latest validation results, click the Validation Report icon.
Chapter 11 - Busbar Commissioning Tool MiCOM P747
308 P747-TM-EN-1
