4.1.7 FUNCTION KEYS
The programmable function keys are available for custom use for devices using 30TE cases or larger.
Factory default settings associate specific functions to these keys, but by using programmable scheme logic,
you can change the default functions of these keys to fit specific needs. Adjacent to these function keys are
programmable tri-colour LEDs, which are set to be associated with their respective function keys.
4.1.8 PROGRAMABLE LEDS
The device has a number of programmable LEDs, which can be associated with PSL-generated signals. All
of the programmable LEDs are tri-colour and can be set to RED, YELLOW or GREEN.
Chapter 3 - Hardware Design MiCOM P747
32 P747-TM-EN-1
