GE MiCOM P747 Agile User Manual

Courier Text Col Row Default Setting Available Options
Description
Coupling 2 CT-3 30 44 0x000000000000000000
0x00000001 Terminal 1
0x00000002 Terminal 2
0x00000004 Terminal 3
0x00000008 Terminal 4
0x00000010 Terminal 5
0x00000020 Terminal 6
0x00000040 Terminal 7
0x00000080 Terminal 8
0x00000100 Terminal 9
0x00000200 Terminal 10
0x00000400 Terminal 11
0x00000800 Terminal 12
0x00001000 Terminal 13
0x00002000 Terminal 14
0x00004000 Terminal 15
0x00008000 Terminal 16
0x00010000 Terminal 17
0x00020000 Terminal 18
This defines which CTs are used for the third bus coupler with two CTs
Coupling 2 CT-4 30 45 0x000000000000000000
0x00000001 Terminal 1
0x00000002 Terminal 2
0x00000004 Terminal 3
0x00000008 Terminal 4
0x00000010 Terminal 5
0x00000020 Terminal 6
0x00000040 Terminal 7
0x00000080 Terminal 8
0x00000100 Terminal 9
0x00000200 Terminal 10
0x00000400 Terminal 11
0x00000800 Terminal 12
0x00001000 Terminal 13
0x00002000 Terminal 14
0x00004000 Terminal 15
0x00008000 Terminal 16
0x00010000 Terminal 17
0x00020000 Terminal 18
This defines which CTs are used for the fourth bus coupler with two CTs
Bus Section 1 30 48 0x1001
0x0001 Zone 1
0x0002 Zone 2
0x0004 Zone 3
0x0008 Zone 4
This define the zones connected to Bus Isolator 1
Bus Section 2 30 49 0x0110
0x0001 Zone 1
0x0002 Zone 2
0x0004 Zone 3
0x0008 Zone 4
This define the zones connected to Bus Isolator 2
5.6 SECURITY CONFIGURATION
Menu Text Col Row Default Setting Available Options
Description
SECURITY CONFIG 25 00
MiCOM P747 Chapter 4 - Configuration
P747-TM-EN-1 95
P747-TM-EN-1.1
