10 COMMISSIONING TEST SETTINGS
Courier Text Col Row Default Setting Available Options
Description
COMMISSION TESTS 0F 00
This column contains settings for the commissioning tests setup
Opto I/P Status 0F 01 Not Settable
This cell displays the status of the fist set of available opto-inputs.
Opto I/P Status2 0F 02 Not Settable
This cell displays the status of the second set of available opto-inputs.
Relay O/P Status 0F 03 Not Settable
This cell displays the status of the available output relays.
Test Port Status 0F 05 Not Settable
This cell displays the logic state of the DDB signals that have been allocated in the Monitor Bit cells.
Monitor Bit 1 to 8 0F 07 to 0E 64 to 71 From 0 to 2047 step 1
The ‘Monitor Bit’ cells allow you to select which DDB signals can be observed in the Test Port Status cell.
Test Mode 0F 0F Disabled
0 = Disabled, 1 = Test Mode, 2 =
Contacts Blocked
This setting allows the test pattern to be sent in the GOOSE message. Using Pass Through, the data in the GOOSE
message is sent as normal. Using Forced, the data sent in the GOOSE message follows the VOP Test Pattern
setting.
Test Pattern 0F 10 0
Binary flag (data type G9)
0=Not Operated
1=Operated
This cell is used to select the output relay contacts to be tested when the Contact Test cell is set to Apply Test.
Contact Test 0F 11 No Operation
0 = No Operation, 1 = Apply Test, 2
= Remove Test
This cell is used to test the output relays.
Test LEDs 0F 12 No Operation 0 = No Operation or 1 = Apply Test
This cell is used to test the user-programmable LEDs. The Apply Test setting forces the LEDs on for 2 secs. The
setting then reverts to No Operation.
Red LED Status 0F 15
Binary string: 0 = not illuminated, 1
= illuminated
This cell indicates which of the user-programmable red LEDs are on.
Green LED Status 0F 16
Binary string: 0 = not illuminated, 1
= illuminated
This cell indicates which of the user-programmable green LEDs are on.
Commissioning mode 0F 18 Disabled 0 = Disabled or 1 = Enabled
This cell allows you to enter commissioning mode by zone or by terminal.
Zone Block Diff. Prot. Mode 0F 19 0000
0x0001 Zone 1
0x0002 Zone 2
0x0004 Zone 3
0x0008 Zone 4
This cell allows you to define the zones in which you want to block the current differential protection function. This may
be during normal operation or to perform secondary injection testing. All other protection functions are operational.
Zone Block Diff. & CBF Prot.
Mode
0F 1A 0000
0x0001 Zone 1
0x0002 Zone 2
0x0004 Zone 3
0x0008 Zone 4
MiCOM P747 Chapter 14 - Commissioning Instructions
P747-TM-EN-1 365
