GE MiCOM P747 Agile User Manual

Courier Text Col Row Default Setting Available Options
Description
This cell sets the nominal voltage for opto-input 31
Opto Input 32 11 21 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 32
Opto Input 33 11 22 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 33
Opto Input 34 11 23 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 34
Opto Input 35 11 24 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 35
Opto Input 36 11 25 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 36
Opto Input 37 11 26 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 37
Opto Input 38 11 27 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 38
Opto Input 39 11 28 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 39
Opto Input 40 11 29 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 40
OptoFilter Ctrl1 11 50 0xFFFFFFFF Binary flag: 0 = Off, 1 = Energised
This setting determines whether the in-built noise filter is off or on for each opto-input.
OptoFilter Ctrl2 11 51 0x000000FF Binary flag: 0 = Off, 1 = Energised
This setting determines whether the in-built noise filter is off or on for each opto-input.
Characteristic 11 80 Standard 60%-80%
0 = Standard 60% to 80% or
1 = 50% to 70%
This setting selects the opto-inputs' pick-up and drop-off characteristics.
5.3.2 OPTO-INPUT LABELS
Courier Text Col Row Default Setting Available Options
Description
GROUP 1
INPUT LABELS
4A 00
This column contains settings for the opto-input Labels
Opto Input 1 4A 01 L1 Not Used ASCII text
This setting defines the label for opto-input 1
Opto Input 2 4A 02 L2 Not Used ASCII text
MiCOM P747 Chapter 6 - Monitoring and Control
P747-TM-EN-1 175
P747-TM-EN-1.1
