Address Name
6 DOD
1 Internet
2 mgmt
1 Mib-2
1 sys
1 sysDescr
3 sysUpTime
4 sysName
Remote Monitoring
16 RMON
1 statistics
1 etherstat
1 etherStatsEntry
9 etherStatsUndersizePkts
10 etherStatsOversizePkts
12 etherStatsJabbers
13 etherStatsCollisions
14 etherStatsPkts64Octets
15 etherStatsPkts65to127Octets
16 etherStatsPkts128to255Octets
17 etherStatsPkts256to511Octets
18 etherStatsPkts512to1023Octets
Redundant Ethernet Board MIB Structurearious SNMP client software tools can be used. Alstom Grid
recommends using an SNMP MIB browser, which can perform the basic SNMP operations such as GET,
GETNEXT and RESPONSE.
Note:
When communicating with the Redundant Ethernet Card, there are two IP addresses visible: one for the IED and one
for the Ethernet switch on the redundant Ethernet board. To access the network using SNMP, use the IP address of
the redundant Ethernet board switch and not that of the IED. See the Configuration chapter for further information.
5.4 SNMP MIB STRUCTURE FOR PRP
Address Name
0 ITU
1 ISO
0 Standard
62439 IECHighavailibility
3 PRP
1 linkRedundancyEntityObjects
0 lreConfiguration
0 lreConfigurationGeneralGroup
1 lreManufacturerName
2 lreInterfaceCount
Chapter 8 - Redundant Ethernet MiCOM P747
254 P747-TM-EN-1
P747-TM-EN-1.1
