Courier Text Col Row Default Setting Available Options
Description
Ctrl Command 31 13 89 SET/RESET
0 = On/Off, 1 = Set/Reset, 2 = In/Out,
3 = Enabled/Disabled
This setting allows you to select the text to be displayed on the hotkey menu.
Control Input 32 13 8C Latched 0 = Latched or 1 = Pulsed
This setting configures the control input as either ‘latched’ or ‘pulsed’.
Ctrl Command 32 13 8D SET/RESET
0 = On/Off, 1 = Set/Reset, 2 = In/Out,
3 = Enabled/Disabled
This setting allows you to select the text to be displayed on the hotkey menu.
5.5.3 CONTROL INPUT LABELS
In the CTRL I/P LABELS column, you can define the text identifiers for the control inputs.
Menu Text Col Row Default Setting Available Options
Description
CTRL I/P LABELS 29 00
This column contains settings for the Control Input Labels
Control Inputs 1 to 32 29 01 to 20 Control Input (n) Extended ASCII text (characters 32 to 234 inclusive)
In this cell you can enter a text label to describe the control input. This text is displayed when a control input is accessed by the hotkey menu and
in the programmable scheme logic description of the control input.
5.5.4 CONTROL INPUT DDB SIGNALS
The number of inputs depends on the model and they are connected to DDB signals as shown in the
following table. The default names are provided, but note that these can be configured in the CTRL I/P
LABELS column.
Ordinal Signal Name Source Type Response
Description
1376 to 1407 Control Input (n) Software Control Protection event
This DDB signal is a control input signal
Chapter 6 - Monitoring and Control MiCOM P747
186 P747-TM-EN-1
