Ordinal Signal Name Source Type Response
Description
216 FnKey LED5 Red Software TRI LED NO RESPONSE
Tri-LED - 13 - Red (Function key LED)
217 FnKey LED5 Grn Software TRI LED NO RESPONSE
Tri-LED - 13 - Green (Function key LED)
218 FnKey LED6 Red Software TRI LED NO RESPONSE
Tri-LED - 14 - Red (Function key LED)
219 FnKey LED6 Grn Software TRI LED NO RESPONSE
Tri-LED - 14 - Green (Function key LED)
220 FnKey LED7 Red Software TRI LED NO RESPONSE
Tri-LED - 15 - Red (Function key LED)
221 FnKey LED7 Grn Software TRI LED NO RESPONSE
Tri-LED - 15 - Green (Function key LED)
222 FnKey LED8 Red Software TRI LED NO RESPONSE
Tri-LED - 16 - Red (Function key LED)
223 FnKey LED8 Grn Software TRI LED NO RESPONSE
Tri-LED - 16 - Green (Function key LED)
224 FnKey LED9 Red Software TRI LED NO RESPONSE
Tri-LED - 17 - Red (Function key LED)
225 FnKey LED9 Grn Software TRI LED NO RESPONSE
Tri-LED - 17 - Green (Function key LED)
226 FnKey LED10 Red Software TRI LED NO RESPONSE
Tri-LED - 18 - Red (Function key LED)
227 FnKey LED10 Grn Software TRI LED NO RESPONSE
5.2.6 LED CONDITIONERS
When driving an LED, the driving signal has to first be conditioned. We need to define certain properties
such as whether it should be latched or not. This is defined in the PSL Editor, which is described in the
Setting Applications Software chapter.
A different set of DDB signals is provided for the purposes of connecting signals such as trips, starts and
alarms, if these signals are to drive the LEDs. The names of these DDB signals are shown below.
5.3 OPTO-INPUTS
Depending on the model, different numbers of opto-inputs are available. The use of these opto-inputs
depends on the application. There are a number of settings associated with the opto-inputs.
5.3.1 OPTO-INPUT CONFIGURATION
Courier Text Col Row Default Setting Available Options
Description
OPTO CONFIG 11 00
This column contains opto-input configuration settings
Global Nominal V 11 01 48-54V
0 = 24-27V, 1 = 30-34V, 2 = 48-54V, 3 =
110-125V, 4 = 220-250V or 5 = Custom
Chapter 6 - Monitoring and Control MiCOM P747
172 P747-TM-EN-1
To Next Page
