Test Result (mark where appropriate)

N/C Watchdog contacts closed? Yes / No

N/O Watchdog contacts open? Yes / No

Measured auxiliary supply ……………………..V DC / AC

1.5 TESTS WITH PRODUCT ENERGISED

General Tests Result (mark where appropriate)

N/C Watchdog contacts open? Yes / No

N/O Watchdog contacts closed? Yes / No

LCD contrast setting used ...............................

Clock set to local time? Yes / No

Time maintained when auxiliary supply removed? Yes / No

Alarm (yellow) LED working? Yes / No

Out of service (yellow) LED working? Yes / No

Programmable LEDs working? Yes / No

All opto-inputs working? Yes / No

All output relays working? Yes / No

1.6 COMMUNICATION TESTS

Communications Result (mark where appropriate)

SCADA Communication standard

(Courier, DNP3.0, IEC

61850, IEC 60870, Modbus)

Communications established? Yes / No

Protocol converter tested? Yes / No / N/A

1.7 CURRENT INPUT TESTS

Current Inputs (if applicable) Result (mark where appropriate)

Displayed current Primary / Secondary

Phase CT ratio (if applicable)

Input CT Applied Value Displayed Value

ISEF (if applicable)

Note:

Reuse the table for each CT tested.

Appendix B - Commissioning Record MiCOM P747
